ADV7174/ADV7179
Rev. B | Page 45 of 52
APPENDIX 6—WAVEFORMS
NTSC WAVEFORMS (WITH PEDESTAL)
130.8 IRE
100 IRE
7.5 IRE
0 IRE
–40 IRE
PEAK COMPOSITE
REF WHITE
SYNC LEVEL
BLANK LEVEL
1268.1mV
1048.4mV
387.6mV
334.2mV
48.3mV
714.2mV
BLACK LEVEL
02980-A-060
Figure 61. NTSC Composite Video Levels
100 IRE
7.5 IRE
0 IRE
–40 IRE
REF WHITE
SYNC LEVEL
BLANK LEVEL
1048.4mV
387.6mV
334.2mV
48.3mV
BLACK LEVEL
714.2mV
02980-A-061
Figure 62. NTSC Luma Video Levels
650mV
335.2mV
963.8mV
0mV
PEAK CHROMA
BLANK/BLACK LEVEL
286mV (p-p)
PEAK CHROMA
629.7mV (p-p)
02980-A-062
Figure 63. NTSC Chroma Video Levels
100 IRE
7.5 IRE
0 IRE
–
40 IRE
REF WHITE
SYNC LEVEL
BLANK LEVEL
1052.2mV
387.5mV
331.4mV
45.9mV
720.8mV
BLACK LEVEL
02980-A-063
Figure 64. NTSC RGB Video Levels
