SPECIFICATIONS
2.8 V SPECIFICATIONS
V
AA
= 2.8 V, V
REF
= 1.235 V, R
SET
= 150 Ω. All specifications T
MIN
to T
MAX
1
, unless otherwise noted.
Table 1.
Parameter Conditions
1
Min Typ Max Unit
STATIC PERFORMANCE
2
Resolution (Each DAC) 10 Bits
Accuracy (Each DAC)
Integral Nonlinearity R
SET
= 300 Ω ±3.0 LSB
Differential Nonlinearity Guaranteed monotonic ±1 LSB
DIGITAL INPUTS
2
Input High Voltage, V
INH
1.6 V
Input Low Voltage, V
INL
0.7 V
Input Current, I
IN
V
IN
= 0.4 V or 2.4 V ±1 μA
Input Capacitance, C
IN
10 pF
DIGITAL OUTPUTS
2
Output High Voltage, V
OH
I
SOURCE
= 400 μA 2.4 V
Output Low Voltage, V
OL
I
SINK
= 3.2 mA 0.4 V
Three-State Leakage Current 10 μA
Three-State Output Capacitance 10 pF
ANALOG OUTPUTS
2
Output Current
3
R
SET
= 150 Ω, R
L
= 37.5 Ω 33 34.7 37 mA
DAC-to-DAC Matching 2.0 %
Output Compliance, V
OC
0 1.4 V
Output Impedance, R
OUT
30 kΩ
Output Capacitance, C
OUT
I
OUT
= 0 mA 30 pF
POWER REQUIREMENTS
2, 4
V
AA
2.8 V
Normal Power Mode
I
DAC
(Max)
5
R
SET
= 150 Ω, R
L
= 37.5 Ω 115 120 mA
I
CCT
6
30 mA
Low Power Mode
I
DAC
(Max)
5
62 mA
I
CCT
6
30 mA
Sleep Mode
I
DAC
7
0.1 μA
I
CCT
8
0.001 μA
Power Supply Rejection Ratio COMP = 0.1 μF 0.01 0.5 %/%
1
Temperature range T
MIN
to T
MAX
: –20°C to +85°C.
2
Guaranteed by characterization.
3
DACs can output 35 mA typically at 2.8 V (R
SET
= 150 Ω and R
L
= 37.5 Ω). Full drive into 37.5 Ω load.
4
Power measurements are taken with clock frequency = 27 MHz. Max T
J
= 110°C.
5
I
DAC
is the total current (min corresponds to 5 mA output per DAC, max corresponds to 37 mA output per DAC) to drive all three DACs. Turning off individual DACs
reduces I
DAC
correspondingly.
6
I
CCT
(circuit current) is the continuous current required to drive the device.
7
Total DAC current in sleep mode.
8
Total continuous current during sleep mode.
