MODE REGISTER 0 (MR0)
Bits: MR07 – MR00
Address: SR4–SR0 = 00H
Figure 38 shows the various operations under the control of Mode Register 0. This register can be read from as well as written to.
CHROMA FILTER SELECT
MR07
MR06
0 0 0 1.3 MHz LOW-PASS FILTER
MR05
0 0 1 0.65 MHz LOW-PASS FILTER
0 1 0 1.0 MHz LOW-PASS FILTER
0 1 1 2.0 MHz LOW-PASS FILTER
1 0 0 RESERVED
1 0 1 CIF
1 1 0 QCIF
1 1 1 RESERVED
MR01
MR00MR07
MR02MR03MR05MR06 MR04
OUTPUT VIDEO
STANDARD SELECTION
MR01
MR00
0 0 NTSC
0 1 PAL (B, D, G, H, and I)
1 0 PAL (M)
1 1 RESERVED
LUMA FILTER SELECT
MR04
MR03
0 0 0 LOW-PASS FILTER (NTSC)
MR02
0 0 1 LOW-PASS FILTER (PAL)
0 1 0 NOTCH FILTER (NTSC)
0 0 1 NOTCH FILTER (PAL)
1 0 0 EXTENDED MODE
1 0 1 CIF
1 1 0 QCIF
1 1 1 RESERVED
02980-A-037
Figure 38. Mode Register 0
Table 9. MR0 Bit Description
Bit Name Bit No. Description
Output Video Standard
Selection
MR01–MR00
These bits are used to set up the ENCODE mode. The ADV7174/ADV7179 can be set up to
output NTSC, PAL (B/D/G/H/I), and PAL (M and N) standard video.
PAL M is available on the ADV7174 only.
Luminance Filter Control MR02–MR04
These bits specify which luminance filter is to be selected. The filter selection is made
independent of whether PAL or NTSC is selected.
Chrominance Filter Control MR05–MR07
These bits select the chrominance filter. A low-pass filter can be selected with a choice of
cutoff frequencies 0.65 MHz, 1.0 MHz, 1.3 MHz, or 2 MHz, along with a choice of CIF or QCIF
filters.
