ADV7174/ADV7179
Rev. B | Page 12 of 52
Table 7. Luminance Internal Filter Specifications
Filter Type
Filter Selection
Pass-Band Ripple
(dB)
3 dB Bandwidth
(MHz)
Stop-Band Cutoff
(MHz)
Stop-Band Attenuation
(dB)
MR04 MR03 MR02
Low-Pass
(NTSC)
0 0 0 0.091 4.157 7.37 −56
Low-Pass
(PAL)
0 0 1 0.15 4.74 7.96 −64
Notch (NTSC) 0 1 0 0.015 6.54 8.3 −68
Notch (PATL) 0 1 1 0.095 6.24 8.0 −66
Extended
(SSAF)
1 0 0 0.051 6.217 8.0 −61
CIF 1 0 1 0.018 3.0 7.06 −61
QCIF 1 1 0 Monotonic 1.5 7.15 −50
Table 8. Chrominance Internal Filter Specifications
Filter Type
Filter Selection
Pass-Band Ripple
(dB)
3 dB Bandwidth
(MHz)
Stop-Band Cutoff
(MHz)
Stop-Band Attenuation
(dB)
MR07 MR06 MR05
1.3 MHz
Low-Pass
0 0 0 0.084 1.395 3.01 −45
0.65 MHz
Low-Pass
0 0 1 Monotonic 0.65 3.64 −58.5
1.0 MHz
Low-Pass
0 1 0 Monotonic 1.0 3.73 −49
2.0 MHz
Low-Pass
0 1 1 0.0645 2.2 5.0 −40
Reserved 1 0 0
CIF 1 0 1 0.084 0.7 3.01 −45
QCIF 1 1 0 Monotonic 0.5 4.08 −50
