54
Version C
Clinician Instructions for Use – Device and Mobile Application
C
IEC 62133-2
Secondary cells and batteries containing alkaline or other non-acid
electrolytes – Safety requirements for portable sealed secondary lithium
cells, and for batteries made from them, for use in portable applications –
Part 2: Lithium systems
BS EN 60601-1-6
Medical Electrical Equipment. General Requirements for Basic
Safety and Essential Performance. Collateral Standard. Usability
BS EN ISO 10993-10
Biological evaluation of medical devices - Part 10: Tests for irritation and
skin sensitization
EN ISO 10993-5
Biological evaluation of medical devices -- Part 5: Tests for in vitro
cytotoxicity
ANSI AAMI EC57
Testing and reporting performance results of cardiac rhythm and ST-
segment measurement algorithms
AAMI TIR69
Risk Management of Radio-Frequency Wireless Coexistence for Medical
Devices and Systems
ISO 27000-1
Information technology — Security techniques — Information security
management systems — Requirements
ISO 14117
Active implantable medical devices — Electromagnetic compatibility —
EMC test protocols for implantable cardiac pacemakers, implantable
cardioverter defibrillators and cardiac resynchronization devices
AAMI/ANSI/IEC 62304
Medical Device Software – Software Life cycle processes
- Guidance for the Content of Premarket Submissions for Software
Contained in Medical Devices
EMC guidance and manufacturer’s declarations
Special precautions concerning electromagnetic compatibility (EMC) must be taken for all medical electrical
equipment. This device complies with IEC 60601-1-2 ed 4.0 (2014-02).
All medical electrical equipment must be installed and put into service in accordance with the EMC
information provided in this document.
Portable and mobile RF communications equipment (e.g: cell phones) can affect the behavior of medical
electrical equipment. The use of accessories and cables other than those specified may result in increased
emissions or decreased immunity.
The device should not be used adjacent to or stacked with other equipment and if adjacent or stacked use is
necessary, it should be observed in order to verify normal operation in the configuration in which it will be
used.
The ADI CPM system complies with all applicable and required standards for electromagnetic interference:
It does not normally affect nearby equipment and devices.
It is not normally affected by nearby equipment and devices.
It is not safe to operate the ADI CPM System in the presence of high-frequency surgical equipment or MRI.
However, it is good practice to avoid using the ADI CPM System in extremely close proximity to other
equipment.
Guidance and Manufacturer’s Declaration – Electromagnetic Emissions
