ABSOLUTE MAXIMUM RATINGS
Table 5.
Parameter
With
Respect to Rating
AVDD and TCVDD AVSS −0.3 V to +3.9 V
HVDD and RGVDD
HVSS,
RGVSS
−0.3 V to +3.9 V
DVDD and DRVDD
DVSS,
DRVSS
−0.3 V to +3.9 V
Any VSS Any VSS −0.3 V to +0.3 V
Digital Outputs DRVSS −0.3 V to DRVDD + 0.3 V
CLPOB/PBLK and HBLK DVSS −0.3 V to DVDD + 0.3 V
SCK, SL, and SDATA DVSS −0.3 V to DVDD + 0.3 V
RG RGVSS −0.3 V to RGVDD + 0.3 V
H1 to H4 HVSS −0.3 V to HVDD + 0.3 V
REFT, REFB, and CCDIN AVSS −0.3 V to AVDD + 0.3 V
Junction Temperature 150°C
Lead Temperature (10 s) 300°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those listed in the operational sections
of this specification is not implied. Exposure to absolute maxi-
mum rating conditions for extended periods may affect device
reliability.
THERMAL CHARACTERISTICS
Thermal Resistance
40-Lead LFCSP Package: θ
JA
= 27°C/W
1
.
1
θ
JA
is measured using a 4-layer PCB with the exposed paddle soldered to the
board.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate
on the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy elec-
trostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance degradation
or loss of functionality.
