Datasheet

AD8027/AD8028
Rev. C | Page 16 of 24
TEMPERATURE (°C)
SUPPLY CURRENT (mA)
–40 –25 –10 5 20 35 50 65 80 11095 125
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
8.5
9.0
V
S
= +3V
V
S
= +5V
V
S
= ±5V
03327-A-053
TIME (ns)
OUTPUT VOLTAGE (V)
0 50 100 150 200 250
–1.5
–1.0
–0.5
0
0.5
1.0
1.5
SELECT PIN (–2.0V TO –0.5V)
OUTPUT
R
L
= 1kΩ
R
L
= 100Ω
R
L
= 10kΩ
G = –1
V
S
= ±2.5V
V
IN
= –1.0V
03327-A-051
Figure 52. Enable Turn-On Timing
Figure 54. Quiescent Supply Current vs. Supply Voltage and Temperature
TIME ( μ s)
OUTPUT VOLTAGE (V)
0.51234567891
–1.5
–1.0
–0.5
0
0.5
1.0
1.5
0
G = –1
V
S
= ± 2.5V
V
IN
= –1.0V
SELECT PIN (–2.0V TO –0.5V)
R
L
= 1k Ω
R
L
= 100 Ω
OUTPUT
R
L
= 10k Ω
03327-A-052
Figure 53. Disable Turn-Off Timing
