Datasheet

AD8013
REV. A
–4–
METALIZATION PHOTO
Contact factory for latest dimensions.
Dimensions shown in inches and (mm).
+IN1
5
+v
s
4
DISABLE 3
3
2 DISABLE 2
1 DISABLE 1
14 OUT 2
–IN1 6
OUT1 7
OUT3 8
–IN3 9
10
+IN3
11
–V
S
12
+IN2
13
–IN2
0.071 (1.81)
0.044 (1.13)
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although
the AD8013 features proprietary ESD protection circuitry, permanent damage may occur on devices
subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are recom-
mended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
SUPPLY VOLTAGE – ± Volts
6
0
172
COMMON-MODE VOLTAGE RANGE – ± Volts
3456
5
4
3
2
1
Figure 1. Input Common-Mode Voltage Range vs.
Supply Voltage
SUPPLY VOLTAGE – ± Volts
12
0
172
OUTPUT VOLTAGE SWING – V p-p
3456
10
8
6
4
2
NO LOAD
R
L
= 150Ω
Figure 2. Output Voltage Swing vs. Supply Voltage
