AD8013–SPECIFICATIONS
Model AD8013A
Conditions V
S
Min Typ Max Units
DYNAMIC PERFORMANCE
Bandwidth (3 dB) No Peaking, G = +2 +5 V 100 125 MHz
No Peaking, G = +2 ±5 V 110 140 MHz
Bandwidth (0.1 dB) No Peaking, G = +2 +5 V 50 MHz
No Peaking, G = +2 ±5 V 60 MHz
Slew Rate 2 V Step +5 V 400 V/µs
6 V Step ±5 V 600 1000 V/µs
Settling Time to 0.1% 0 V to +2 V ±5 V 18 ns
4.5 V Step, C
LOAD
= 200 pF ±6 V 40 ns
R
LOAD
> 1 kΩ, R
FB
= 4 kΩ
NOISE/HARMONIC PERFORMANCE
Total Harmonic Distortion f
C
= 5 MHz, R
L
= 1 k ±5 V –76 dBc
f
C
= 5 MHz, R
L
= 150 Ω±5 V –66 dBc
Input Voltage Noise f = 10 kHz +5 V, ±5 V 3.5 nV/√
Hz
Input Current Noise f = 10 kHz (–I
IN
) +5 V, ±5 V 12 pA/√Hz
Differential Gain (R
L
= 150 Ω) f = 3.58 MHz, G = +2 +5 V
1
0.05 %
±5 V 0.02 0.05 %
Differential Phase (R
L
= 150 Ω) f = 3.58 MHz, G = +2 +5 V
1
0.06 Degrees
±5 V 0.06 0.12 Degrees
DC PERFORMANCE
Input Offset Voltage T
MIN
to T
MAX
+5 V, ±5 V 2 5 mV
Offset Drift 7 µV/°C
Input Bias Current (–) +5 V, ±5 V 2 10 µA
Input Bias Current (+) T
MIN
to T
MAX
+5 V, ±5 V 3 15 µA
Open-Loop Transresistance +5 V 650 800 kΩ
T
MIN
to T
MAX
550 kΩ
±5 V 800 k 1.1 M Ω
T
MIN
to T
MAX
650 kΩ
INPUT CHARACTERISTICS
Input Resistance +Input ±5 V 200 kΩ
–Input ±5 V 150 Ω
Input Capacitance ±5 V 2 pF
Input Common-Mode Voltage Range ±5 V 3.8 ±V
+5 V 1.2 3.8 +V
Common-Mode Rejection Ratio
Input Offset Voltage +5 V 52 56 dB
Input Offset Voltage ±5 V 52 56 dB
–Input Current +5 V, ±5 V 0.2 0.4 µA/V
+Input Current +5 V, ±5 V 5 7 µA/V
OUTPUT CHARACTERISTICS
Output Voltage Swing
R
L
= 1 kΩ V
OL
–V
EE
0.8 1.0 V
V
CC
–V
OH
0.8 1.0 V
R
L
= 150 Ω V
OL
–V
EE
1.1 1.3 V
V
CC
–V
OH
1.1 1.3 V
Output Current +5 V 30 mA
±5 V 25 30 mA
Short-Circuit Current ±5 V 95 mA
Capacitive Load Drive ±5 V 1000 pF
MATCHING CHARACTERISTICS
Dynamic
Crosstalk G = +2, f = 5 MHz +5 V, ±5 V 70 dB
Gain Flatness Match f = 20 MHz ±5 V 0.1 dB
DC
Input Offset Voltage +5 V, ±5 V 0.3 mV
–Input Bias Current +5 V, ±5 V 1.0 µA
(@ T
A
= +258C, R
LOAD
= 150 V, unless otherwise noted)
–2–
REV. A
