www.rosemount.com

Rosemount 5300 Series

October 2014

ID DN80, PN100

H, P, C

★

JA DN100, PN16 S, H, P, C

★

JB DN100, PN40 S, H, P, C

★

JC DN100, PN63 H, P, C

★

JD DN100, PN100

H, P, C

★

HE DN50, PN160

H, P, C

HF DN50, PN250

H, P, C

HI DN50, PN40, EN 1092-1 Type E spigot face (DIN 2513 Form V13) S, H, P, C

HP DN50, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

HQ DN50, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

IE DN80, PN160

H, P, C

IF DN80, PN250

H, P, C

IH DN80, PN16, EN 1092-1 Type E spigot face (DIN 2513 Form V13) S, H, P, C

II DN80, PN40, EN 1092-1 Type E spigot face (DIN 2513 Form V13) S, H, P, C

IP DN80, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

IQ DN80, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

JE DN100, PN160

H, P, C

JF DN100, PN250

H, P, C

JH DN100, PN16, EN 1092-1 Type E spigot face (DIN 2513 Form V13) S, H, P, C

JI DN100, PN40, Type E spigot face (DIN 2513 Form V13) S, H, P, C

JP DN100, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

JQ DN100, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F) S, H, P, C

KA DN150, PN16 S, H, P, C

JIS flanges

(17)(19)

Operating temperature and

pressure

UA 50A, 10K S, H, P, C

★

VA 80A, 10K S, H, P, C

★

XA 100A, 10K S, H, P, C

★

UB 50A, 20K S, H, P, C

VB 80A, 20K S, H, P, C

XB 100A, 20K S, H, P, C

YA 150A, 10K S, H, P, C

YB 150A, 20K S, H, P, C

ZA 200A, 10K S, H, P, C

Table 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information

The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject

to additional delivery lead time.
