Product data

7
www.rosemount.com
Rosemount 5300 Series
October 2014
Probe type Process connection Probe lengths
3B
Coaxial, perforated. For level and interface
measurement.
Flange / 1-in.
(8)
, 1½-in.,
2- in.
(8)
Thread
Min: 1 ft 4 in. (0.4 m)
Max: 19 ft 8 in. (6 m)
★
3V
Integrated Still Pipe Vapor Probe. For 3-in.
chambers and above.
(10)
Refer to page 13 to specify reference reflector
length.
Flange
Min: 2 ft 11 in. (0.9 m) for the
short reflector (R1 option)
Min: 3 ft 7 in. (1.1 m) for the
long reflector (R2 option)
Max: 13 ft 1 in. (4 m)
★
4A Rigid Single Lead (8 mm)
Flange / 1- in.
(8)
, 1½-in.,
2- in.
(8)
Thread / Tri-Clamp™
Min: 1 ft 4 in. (0.4 m)
Max: 9 ft 10 in. (3 m)
★
4B Rigid Single Lead (13mm)
(9)
Flange / 1-in., 1½-in.,
2-in. Thread / Tri-Clamp
Min: 1 ft 4 in. (0.4 m)
Max: 19 ft 8 in. (6 m)
★
4U
Single Rigid Vapor Probe (equipped with a 1½-in.
centering disc). For 2-in. chambers.
(10)
Refer to page 13 to specify reference reflector
length.
Flange / 1½-in. Thread
Min: 2 ft 11 in. (0.9 m) for the
short reflector (R1 option)
Min: 3 ft 7 in. (1.1 m) for the
long reflector (R2 option)
Max: 7.5 ft (2.3 m)
★
5A Flexible Single Lead with weight
(11)
Flange / 1-in.
(8)
, 1½-in.,
2-in.
(8)
Thread / Tri-Clamp
Min: 3 ft 4 in. (1 m)
Max: 164 ft (50 m)
★
5B Flexible Single Lead with chuck
(12)
Flange / 1-in.
(8)
, 1½-in.,
2-in.
(8)
Thread / Tri-Clamp
Min: 3 ft 4 in. (1 m)
Max: 164 ft (50 m)
★
1A Rigid Twin Lead
(8)
Flange / 1½-in., 2-in.
(8)
Thread
Min: 1 ft 4 in. (0.4 m)
Max: 9 ft 10 in. (3 m)
2A Flexible Twin Lead with weight
(8)
Flange / 1½-in., 2-in.
(8)
Thread
Min: 3 ft 4 in. (1 m)
Max: 164 ft (50 m)
3A Coaxial (for level measurement)
(13)
Flange / 1-in.
(8)
, 1½-in.,
2-in.
(8)
Thread
Min: 1 ft 4 in. (0.4 m)
Max: 19 ft 8 in. (6 m)
4S Segmented Rigid Single Lead (13mm)
Flange / 1-in., 1½-in.,
2-in.
Thread / Tri-Clamp
Min: 1 ft 4 in. (0.4 m)
Max: 32 ft 9 in. (10 m)
Probe length units
E English (feet, in.)
★
M Metric (meters, centimeters)
★
Total probe length
(14)
(feet/m)
XXX 0-164 ft or 0-50 m
★
Total probe length
(14)
(in./cm)
XX 0-11 in. or 0-99 cm
★
Process connection - size / type (consult the factory for other process connections)
ASME / ANSI flanges
(15)(16)
Operating temperature and
pressure
AA 2 in., 150 lb
S, H, P, C
★
AB 2 in., 300 lb S, H, P, C
★
Table 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
