Product data

66
www.rosemount.com
Rosemount 5300 Series
October 2014
Figure 9. Single Rigid Vapor Probe for 2-in. Chambers
Dimensions are in inches (millimeters).
7.1 (180)
3.4 (87) 3.6 (92)
16 (397)
4.3
(109)
9 (226)
NPT 1½ in., s50
BSP-G 1½ in., s60
The probe must be in the
center of the chamber/pipe
Water surface
Min. 12 (300)
1½-in. centering disc
Ø 1.46 (37)
Water
surface
Short reflector: 13.8 (350)
Long reflector: 19.7 (500)
Minimum 8.3 in. (210 mm)
distance between water
surface and reflector end
Ø 0.3 (8)
Pipe inner diameter:
Ø 1.5 (38) - Ø 2.05 (52)
5.2 (133)
Ø 0.5 (13)
L
 7.5 ft
(2.3 m)
1.1 (27)
Chamber
flange
Thread sealing
Chamber/pipe (metal)
Upper reference point
W/O housing
½ - 14 NPT
Optional adapters:
M20x1.5, eurofast
and minifast
