Rosemount 5300 Series
October 2014
Figure 8. Segmented Rigid Single Lead Probe with Threaded Connection
Dimensions are in inches (millimeters).
7.1 (180)
3.4 (87) 3.6 (92)
½ - 14 NPT
Optional adapters:
M20x1.5, eurofast
and minifast
L
 33 ft (10 m)
10.1 (257.5)
Ø 0.51 (13)
15.2 (385)
31.5 (800)
Optional: Bottom centering
disc (SST or PTFE)
0.6 (15)
7.4 (188.5)
5.2 (133)
HTHP/HP/C version
Optional:
PTFE centering disc
NPT 1 in., s52
NPT 1½ in., s52
NPT 2 in., s60
2.4 (62)
BSP-G 1 in., s52
BSP-G 1½ in., s60
1.1 (27) 2.4 (62)
55 (2.2)
15.2 (385)
NPT 1½ in., s50
BSP-G 1½ in., s60
