Rosemount 5300 Series
October 2014
Figure 7. Segmented Rigid Single Lead Probe with Flange Connection
Dimensions are in inches (millimeters).
7.1 (180)
3.4 (87) 3.6 (92)
½ - 14 NPT
Optional adapters:
M20x1.5, eurofast
and minifast
L
 33 ft (10 m)
10.1 (257.5)
Ø 0.51 (13)
15.2 (385)
31.5 (800)
Optional: Bottom centering disc (SST or PTFE)
0.6 (15)
7.4 (188.5)
5.2 (133)
HTHP/HP/C version
15.6 (397.5)
55 (2.2)
15.2 (385)
Optional: PTFE centering disc
