Rosemount 5300 Series
October 2014
E M12, 4-pin, Male connector (eurofast
®
)
(1)
★
M A size Mini, 4-pin, Male connector (minifast
®
)
(1)
★
Operating temperature and pressure (see page 31)
(2)
Probe type
S
Standard
- 15 psig (-1bar) to 580 psig (40 bar) @ 302 °F (150 °C)
1A, 2A, 3A, 3B, 4A, 4B, 4S,
5A, and 5B
★
H
High Temperature / High Pressure
(3)
:
2940 psi @ 752 °F and 5000 psi @ 100 °F
(203 bar @ 400 °C and 345 bar @ 38 °C)
3A, 3B, 3V, 4A, 4B, 4S, 4U,
5A, and 5B
★
P
High Pressure
(3)
:
Max 392 °F (200 °C): 3500 psi @ 392 °F and 5000 psi @ 100 °F (243 bar @ 200 °C
and 345 bar @ 38 °C)
3A, 3B, 4A, 4B, 4S, 5A, and 5B
★
C
Cryogenic Temperature
(3)(4)
-321 °F (-196 °C)
Max 392 °F (200 °C): 3500 psi @ 392 °F and 5000 psi @ 100 °F (243 bar @ 200 °C
and 345 bar @ 38 °C)
3A, 3B, 4A, 4B, 4S, 5A, 5B
(Only SST)
Material of construction
(5)
:
Process connection / probe
Probe type Valid operation
temperature and pressure
1 316L SST (EN 1.4404) All S, H, P, C
★
2
Alloy C-276 (UNS N10276). With plate design if
flanged version. Up to class 600/PN 63 for
HTHP/HP probes.
3A, 3B, 4A S, H, P
3
Alloy 400 (UNS N04400). With plate design if
flanged version.
3A, 3B, 4A, 5A, 5B S
7
PTFE covered probe and flange. With plate
design.
4A and 5A S
8 PTFE covered probe 4A and 5A S
H
Alloy C-276 (UNS N10276) process connection,
flange, and probe
(6)
3A, 3B, 4A H, P
D
Duplex 2205 (UNS S31803) process connection,
flange, and probe
4B S, H, P
Sealing, o-ring material (consult the factory for other o-ring materials)
NNone
(7)
★
VViton
®
Fluoroelastomer
★
E Ethylene Propylene (EPDM)
★
KKalrez
®
6375 Perfluoroelastomer
★
B Nitrile Butadiene (NBR)
★
Table 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
