Rosemount 5300 Series
October 2014
EAC certifications
Technical Regulations Customs Union (EAC)
EM, IM: Contact an Emerson Process Management
representative for additional information.
Brazilian certifications
INMETRO approvals
Special Conditions for Safe Use (X):
Letter X in the number of the certificate indicates the following
special condition(s) for safe use:
 For models 530xFxxxxxxxxxE1..., 530xFxxxxxxxxxKA...,
530xFxxxxxxxxxKB... or 530xFxxxxxxxxxKC... and when the
sensor area requires an EPL Ga, the installation of the
transmitter on the process wall must be done in a way that
ensures the minimum degree of protection IP67 in the
connection, in compliance with regulation ABNT NBR IEC
60529.
 The intrinsically safe circuit did not withstand the dielectric
rigidity tests with 500 Vca as specified in clause 6.4.12 of
regulation IEC 60079-11.
 Probes covered with plastic or plastic discs should have a
non-conductive area not exceeding the maximum permitted
area for the MC group, which is 4 cm
2
. Therefore, when an
antenna is used in a potentially explosive atmosphere,
appropriate measures should be taken by the user to prevent
electrostatic discharge.
 This equipment contains light metals. The equipment must
be installed in a way that the risk of impact or friction with
other metal surfaces is eliminated.
 The Ex ia version of the field device of model FISCO 5300 can
be provided with a FISCO [Ex ib] power supply when the power
supply is certified with three current limiter safety devices
separately and with limitation of voltage, complying with the
requirements of the Ex ia model.
Certificate: NCC 14.2258X
Standards:
ABNT NBR IEC: 60079-0:2013, 60079-1:2009, 60079-11:2009,
60079-26:2008, 60079-27:2010, 60079-31:2011
E2 Flameproof:
4-20 mA/HART model:
Ex d ia IIC T4 Gb/Ga
Ex ta IIIC T79 °C
-40 °C <
Ta < +70 °C
U
m
: 250 V
F
OUNDATION fieldbus model:
Ex d ia IIC T4 Gb/Ga
Ex ta IIIC T69 °C
-40 °C <
Ta < +60 °C
U
m
: 250 V
MODBUS model:
Ex d ia IIC T4 Gb/Ga
Ex ta IIIC T79 °C
-40 °C <
Ta < +70 °C
U
m
: 250 V
I2 Intrinsically safe:
4-20 mA/HART model:
Ex ia IIC T4 Ga
Ex ta IIIC T79 °C
-50 °C <
Ta < +70 °C
U
i
: 30 V, I
i
: 130 mA, P
i
: 1.0 W, L
i
: 0 μH, C
i
: 7.26 nF
FOUNDATION fieldbus model:
Ex ia IIC T4 Ga
Ex ta IIIC T69 °C
-50 °C <
Ta < +60 °C
U
i
: 30 V, I
i
: 300 mA, P
i
: 1.5 W, L
i
: 0 μH, C
i
: 4.95 nF
Installation Drawing: 9240030-938
IB FISCO model:
FISCO Field Device
Ex ia IIC T4 Ga
Ex ia/ib IIC T4 Ga/Gb
Ex ta IIIC T69 °C
-50 °C <
Ta < +60 °C
U
i
: 17.5 V, I
i
: 380 mA, P
i
: 5.32 W, L
i
: <1 μH, C
i
: 4.95 nF
Installation Drawing: 9240030-938
