Product Certifications
EU conformity
The most recent revision of the EC declaration of conformity can
be found at www.rosemount.com.
Safety Instrumented Systems (SIS)
SIL 3 Capable: IEC 61508 certified by an accredited 3rd party
agency for use in safety instrumented systems up to SIL 3
(Minimum requirement of single use (1oo1) for SIL 2 and
redundant use (1oo2) for SIL 3).
For more information, go to:
http://www.rosemount.com/safety
Hazardous locations certifications
North-American certifications
Factory Mutual (FM) Approval
Project ID: 3020497
E5 Explosion-proof:
Explosion-proof for Class I, Div. 1, Groups B, C, and D.
Dust-ignition-proof for Class II/III, Div. 1, Groups E, F, and G
with Intrinsically Safe connections to Class I, II, III, Div. 1,
Groups B, C, D, E, F, and G.
Temp. Code T4
Ambient temperature limits: -50 °C to +70 °C
(1)
.
Seal not required.
Approval valid for HART, F
OUNDATION fieldbus, and Modbus
options.
I5, IE Intrinsically Safe, Non-Incendive, and FISCO model:
Intrinsically Safe for Class I, II, III, Div. 1, Groups A, B, C, D, E,
F, and G.
Class I, Zone 0, AEx ia IIC T4 when installed per Control
Drawing: 9240 030-936.
Non-Incendive Class I, Div. 2, Groups A, B, C, D, F, and G;
Suitable for Class II, III, Div. 2, Groups F and G;
4-20 mA/HART model: U
i
= 30 Vdc, I
i
= 130 mA, P
i
= 1.0 W,
C
i
= 7.26 nF, L
i
= 0 H.
Max. operation: 42.4 V, 25 mA
F
OUNDATION fieldbus model: U
i
= 30 Vdc, I
i
= 300 mA,
P
i
= 1.3 W, C
i
= 0 nF, L
i
= 0 H.
Max. operation: 32 V, 25 mA
FISCO model: U
i
= 17.5 Vdc, I
i
= 380 mA, P
i
= 5.32 W,
L
i
= C
i
= 0.
Temp. Code T4
Ambient temperature limits: -50 °C to +70 °C
(1)
Approval valid for HART, FOUNDATION fieldbus, and FISCO
options.
Specific Conditions of Use:
WARNING: To prevent ignition of flammable or combustible
atmospheres, read, understand and adhere to the
manufacturer's live maintenance procedures.
WARNING: Substitution of components may impair Intrinsic
Safety.
WARNING: Potential Electrostatic Charging Hazard – The
enclosure is constructed from a non-metallic material. To
prevent the risk of electrostatic sparking the plastic surface
should only be cleaned with a damp cloth.
WARNING: The apparatus enclosure contains aluminum and is
considered to constitute a potential risk of ignition by impact or
friction. Care must be taken into account during installation and
use to prevent impact or friction.
Canadian Standards Association (CSA) Approval
Certificate: 1514653
Product options bearing the Dual Seal marking meets the Dual
Seal Requirements of ANSI/ISA12.27.01-2003.
Dual seal annunciation
The breach of the secondary seal is annunciated via product
leakage from the antenna’s vents. The leakage will be visible
and/or audible from the transmitter head’s threads.
Dual seal maintenance
No maintenance required. Verify proper operation by keeping
leak path free from ice or contamination.
(1) +60 °C with FOUNDATION fieldbus or FISCO option.
