Rosemount 5300 Series
October 2014
Table 15. Centering Disc Dimensions
Table 16. Centering Disc Size Recommendation for Different Pipe Schedules
Table 17. Centering Disc Size Recommendations for Rosemount 9901 Chambers
Disc size Actual disc diameter
2 in. 1.8 in. (45 mm)
3 in. 2.7 in. (68 mm)
4 in. 3.6 in. (92 mm)
6 in. 5.55 in. (141 mm)
8 in. 7.40 in. (188 mm)
Pipe size Pipe schedule
5s, 5 10s, 10 40s, 40 80s, 80 120 160
2 in. 2 in. 2 in. 2 in. 2 in. NA
(1)
(1) Schedule is not available for pipe size.
NA
(2)
(2) No centering disc is available.
3 in. 3 in. 3 in. 3 in. 3 in. NA
(1)
2 in.
4 in. 4 in. 4 in. 4 in. 4 in. 4 in. 3 in.
5 in. 4 in. 4 in. 4 in. 4 in. 4 in. 4 in.
6 in. 6 in. 6 in. 6 in. 6 in. 4 in. 4 in.
7 in. NA
(1)
NA
(1)
6 in. 6 in. NA
(1)
NA
(1)
8 in. 8 in. 8 in. 8 in. 8 in. 6 in. 6 in.
Chamber size Chamber rating Centering disc
3 in.
Up to Class 600/PN 100 3 in.
Class 900, 1500/PN160, 250 2 in.
3 in. T-piece Up to Class 600/PN 100 2 in.
4 in.
Up to Class 600/PN 100 4 in.
Class 900, 1500/PN160, 250 3 in.
