Rosemount 5300 Series
October 2014
Flange Dimensions
Follows ASME B 16.5, JIS B2220, and EN 1092-1 standards for blind flanges.
For Proprietary Fisher
®
and Masoneilan
®
flanges, see “Special flanges and flushing connection
rings” on page 77
Vented Flanges
Available with Masoneilan and Fisher vented flanges. Vented flanges must be ordered as
accessories with a 1½-in. NPT threaded process connection (code RA); see “Special flanges and
flushing connection rings” on page 77. As an alternative to a vented flange, it is possible to use a
flushing connection ring on top of the standard nozzle.
Probe Versions
Coaxial, Rigid Twin and Rigid Single Lead, Flexible Twin and Flexible Single Lead. Probes can be
ordered in different materials and options for extreme temperatures and pressure.
For guidelines on which probe to select depending on application, see the Technical Note
Guided Wave Radar Application Guidelines (document number 00840-2600-4811)
Material Exposed To
Tank Atmosphere
Standard Probe (Operating Temperature and Pressure code S):
 Material model code 1 (probe types 6A and 6B): 316L SST (EN 1.4404), Duplex 2507 (UNS
S32750/EN 1.4410), PTFE, PFA, and O-ring materials
 Material model code 1 (all other probe types): 316L SST (EN 1.4404), PTFE, PFA, and O-ring
materials
 Material model code 2: Alloy C-276 (UNS N10276), PTFE, PFA, and O-ring materials
 Material model code 3: Alloy 400 (UNS N04400), Alloy K500, PTFE, PFA, and O-ring materials
 Material model code 7: PTFE (1 mm PTFE cover)
 Material model code 8: PTFE, 316 L SST (EN 1.4404), and O-ring materials
 Material model code D: Duplex 2205 (UNS S31803/EN 1.4462), Duplex 2507 (UNS
S32750/EN 1.4410), PTFE, PFA, and O-ring materials
HTHP Probe (Operating Temperature and Pressure code H):
 Material model code 1: 316L SST (EN 1.4404), Ceramic (Al2O3), Graphite, and Alloy 625
 Material model code 2 and H: Alloy C-276 (UNS N10276), Ceramic (Al2O3), Graphite, and
Alloy 625
 Material model code D: Duplex 2205 (UNS S31803/EN 1.4462), Ceramic (Al2O3), Graphite,
and Alloy 625
HP Probe (Operating Temperature and Pressure code P):
 Material model code 1: 316L SST (EN 1.4404), Ceramic (Al2O3), Graphite, PFA, PTFE, and
Alloy 625
 Material model code 2 and H: Alloy C-276 (UNS N10276), Ceramic (Al2O3), Graphite, PFA,
PTFE, and Alloy 625
 Material model code D: Duplex 2205 (UNS S31803/EN 1.4462), Ceramic (Al2O3), Graphite,
PFA, PTFE, and Alloy 625
Cryogenic Probe (Operating Temperature and Pressure code C):
 Material model code 1: 316L SST (EN 1.4404), Ceramic (Al2O3), Graphite, PFA, PTFE, and
Alloy 625
Pressure Equipment Directive
(PED)
Complies with 97/23/EC article 3.3
