Rosemount 5300 Series
October 2014
Table 10. Maximum Recommended Viscosity and Coating / Build-up
Table 9. Remote Housing Measuring Range
Dielectric
constant
Rigid single
8 mm
Rigid single
13 mm/
segmented
rigid single
Flexible single Coaxial Rigid twin Flexible twin
1 m remote housing
Chamber /
pipe
installations 
4 in. (100 mm)
1.4 4 ft (1.25 m) 19 ft (6 m)
(1)
33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
2 10 ft (3 m)
(1)
19 ft (6 m)
(1)
33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
80 10 ft (3 m) 19 ft (6 m)
(1)
33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
Tank
installations
1.4 4 ft (1.25 m) 4 ft (1.25 m) 4 ft (1.25 m) 19 ft (6 m) 4 ft (1.25 m) 4 ft (1.25 m)
2 4 ft (1.25 m) 4 ft (1.25 m) 4 ft (1.25 m) 19 ft (6 m) 4 ft (1.25 m) 98 ft (30 m)
(1)
80 10 ft (3 m)
(1)
10 ft (3 m)
(1)
159 ft (48.5 m)
(1)
19 ft (6 m) 10 ft (3 m)
(1)
159 ft (48.5 m)
(1)
2 m remote housing
Chamber /
pipe
installations 
4 in. (100 mm)
1.4 9 ft (2.75 m) 19 ft (6 m)
(1)
33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
2 10 ft (3 m)
(1)
19 ft (6 m)
(1)
33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
80 10 ft (3 m) 19 ft (6 m) 33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
Tank
installations
1.4 9 ft (2.75 m) 9 ft (2.75 m) 9 ft (2.75 m) 19 ft (6 m) 9 ft (2.75 m) 9 ft (2.75 m)
2 9 ft (2.75 m) 9 ft (2.75 m) 9 ft (2.75 m) 19 ft (6 m) 9 ft (2.75 m) 98 ft (30 m)
(1)
80 10 ft (3 m)
(1)
10 ft (3 m)
(1)
154 ft (47 m)
(1)
19 ft (6 m) 10 ft (3 m)
(1)
154 ft (47 m)
(1)
3 m remote housing
Chamber /
pipe
installations 
4 in. (100 mm)
1.4 10 ft (3 m) 19 ft (6 m) 33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
2 10 ft (3 m) 19 ft (6 m) 33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
80 10 ft (3 m) 19 ft (6 m) 33 ft (10 m)
(1)(2)
19 ft (6 m) 10 ft (3 m)
(1)
33 ft (10 m)
(1)(2)
Tank
installations
1.4 10 ft (3 m) 14 ft (4.25 m) 14 ft (4.25 m) 19 ft (6 m) 10 ft (3 m)
(1)
14 ft (4.25 m)
2 10 ft (3 m) 14 ft (4.25 m) 14 ft (4.25 m) 19 ft (6 m) 10 ft (3 m)
(1)
98 ft (30 m)
(1)
80 10 ft (3 m) 19 ft (6 m)
(1)
149 ft (45.5 m)
(1)
19 ft (6 m) 10 ft (3 m)
(1)
149 ft (45.5 m)
(1)
(1) Accuracy may be affected up to + 1.2 in. (30 mm).
(2) Required chamber/pipe size is 3 or 4 in. (75 -100 mm).
Coaxial Twin lead Single lead
Maximum viscosity 500 cP 1500 cP 8000 cP
(1)(2)(3)
(1) Consult your local Emerson Process Management representative in the case of agitation/turbulence and high viscous products.
(2) Be cautious in HTHP viscous or crystallizing media applications where temperature at instrument connection is significantly lower than process temperature
with risk of coating in the upper part of probe that may reduce the measurement signal. Consider using HP or STD probes in such applications.
(3) For viscous or sticky applications, it is not recommended to use centering discs mounted along the probe.
Coating / build-up Coating not recommended Thin coating allowed, but no bridging Coating allowed
