Rosemount 5300 Series
October 2014
Table 8. Measuring Range and Minimum Dielectric Constant
Rigid single lead/
segmented rigid
single lead
Flexible single lead
(1)
Coaxial Rigid twin Lead Flexible twin lead
Maximum
measuring
range
9 ft. 10 in. (3 m)
for 8 mm probes
(code 4A)
19 ft. 8 in. (6 m)
for 13 mm probes
(code 4B)
32 ft 9 in. (10 m)
for 13 mm probes
(code 4S)
164 ft (50 m)
19 ft 8 in.
(6 m)
9 ft 10 in. (3 m) 164 ft (50 m)
Minimum
dielectric
constant
1.4 (Std)
(1.25 if installed in a
metallic bypass or
stilling well)
(1)(2)
1.6 (HP/HTHP/C)
(1.4 if installed in a
metallic bypass or
stilling well)
(1)(2)
(1) Probe end projection software function will improve the minimum measurable dielectric constant. Consult the factory for details.
(2) May be lower depending on installation.
1.4 (Std), up to 49 ft (15 m)
(1)
1.6 (HP/HTHP/C),
up to 49 ft (15 m)
(1)
(Std/HP/HTHP/C)
1.8, up to 82 ft (25 m)
(1)
2.0, up to 115 ft (35 m)
(1)
3, up to 138 ft (42 m)
4, up to 151 ft (46 m)
6, up to 164 ft (50 m)
1.2 (Std)
1.4 (HP/C)
2.0 (HTHP)
1.4 (Std)
(Std)
1.4, up to 82 ft (25 m)
(1)
2.0, up to 115 ft (35 m)
(1)
2.5, up to 131 ft (40 m)
(1)
3.5, up to 148 ft (45 m)
6, up to 164 ft (50 m)
