Product data

39
www.rosemount.com
Rosemount 5300 Series
October 2014
Performance specifications
General
Reference Conditions
Single Standard probe, 77°F (25°C) in water (DC=80) and ambient pressure in a 4” pipe using
Trim Near Zone function.
Reference Accuracy ± 0.12 in. (3 mm) or 0.03% of measured distance, whichever is greatest
(1)
Repeatability ± 0.04 in. (1 mm)
Ambient Temperature Effect ± 0.008 in. (0.2 mm) /°K or ± 30 ppm/°K of measured value, whichever is greatest
Update Interval Minimum 1 update per second
Environment
Vibration Resistance Aluminum housing: IEC 60770-1 Level 1. Stainless Steel housing: IACS E10
Electromagnetic Compatibility
Emission and Immunity: EMC directive 2004/108/EC, EN61326-1:2006 and
EN61326-3-1:2006. NAMUR recommendations NE21
Installations with High Transients
(e.g. thunderstorms)
To fully mitigate unwanted restarts caused by high transients on an installation, one of the
below guidelines must be followed:
 Use Ex ia (Intrinsically Safe) units
 Use an isolator to prevent transients from reaching the transmitter barrier
 Use an alarm delay in your host logic to mask out nuisance alarms (equal to or greater than
transmitter startup time)
Built-in Lightning Protection
EN61326, IEC 801-5, level 1 kV.
T1 option: the transmitter complies with IEEE 587 Category B transient protection and IEEE
472 surge protection
Coating
(See Table 10 on page 45)
 Single lead probes are preferred when there is a risk of contamination (because coating can
result in the product bridging across the two leads for twin versions; between the inner
lead and outer pipe for the coaxial probe).
 For viscous or sticky applications, PTFE probes are recommended. Periodic cleaning may
also be required.
 For viscous or sticky applications, it is not recommended to use centering discs mounted
along the probe.
 Signal Quality Metrics (option code D01, or DA1) can be used in determining when to clean
the probe.
Transmitters equipped with the Diagnostics Suite option can calculate Signal
Quality Metrics.
 Maximum error due to coating is 1-10% depending on probe type, dielectric constant,
coating thickness and coating height above product surface
CE-mark Complies with applicable directives (EMC, ATEX)
(1) For probes with spacers, the accuracy may deviate close to the spacers. Accuracy may be affected by remote housing.
