Rosemount 5300 Series
October 2014
Table 4. Temperature Ranges for Standard Tank Seals with Different O-ring Materials
Note
Always check the chemical compatibility of the o-ring material with your application.
Table 5. 316L SST and Process Connection with Plate Design: Conditions Used for Flange Strength Calculations
Table 6. Alloy C-276: Conditions Used for Flange Strength Calculations
Table 7. Duplex 2205: Conditions Used for Flange Strength Calculations
Tank seal with different o-ring material Min. temperature °F (°C) in air Max. temperature °F (°C) in air
Viton
®
Fluoroelastomer 5 (-15) 302 (150)
Ethylene Propylene (EPDM) -40 (-40) 266 (130)
Kalrez
®
6375 Perfluoroelastomer 14 (-10) 302 (150)
Nitrile Butadiene (NBR) -31 (-35) 230 (110)
Bolting material Gasket Flange material Hub material
Standard/HP/HTHP/C HP/HTHP/C
ASME /
ANSI
Stainless steel
SA193 B8M Cl.2
Soft (1a) with min.
thickness 1.6 mm.
Spiral wound gasket with
nonmetallic filler (1b)
Stainless steel A182
Gr. F316L and
EN 10222-5-1.4404.
Stainless steel
SA479M 316L, and
EN 10272-1.4404.
EN, JIS
EN 1515-1/-2 group
13E0, A4-70.
Soft (EN 1514-1) with
min. thickness 1.6 mm.
Spiral wound gasket with
nonmetallic filler
(EN 1514-2)
Bolting material Gasket Flange material Hub material
Standard/HP/HTHP HP/HTHP
ASME /
ANSI
UNS N10276
Soft (1a) with min.
thickness 1.6 mm
Spiral wound gasket with
nonmetallic filler (1b)
SB462 Gr. N10276
(solution annealed
condition) or SB575
Gr. N10276 (solution
annealed condition)
SB574 Gr. N10276
EN, JIS
Soft (EN 1514-1) with
min. thickness 1.6 mm
Spiral wound gasket with
nonmetallic filler
(EN 1514-2)
Bolting material Gasket Flange material Hub material
Standard/HTHP HP/HTHP
ASME /
ANSI
A193 B7 or
A320 L7
Soft (1a) with min.
thickness 1.6 mm
Spiral wound gasket with
nonmetallic filler (1b)
Duplex stainless steel
SA/A182 F51 and
EN10222-5-1.4462
or SA/A240 Gr.
S31803 and
EN10028-7-1.4462
Stainless steel
SA479M S31803 and
EN 10272-1.4462
EN, JIS Bumax 88
Soft (EN 1514-1) with
min. thickness 1.6 mm
Spiral wound gasket with
nonmetallic filler
(EN 1514-2)
