Rosemount 5300 Series
October 2014
Display and configuration
Integral Display
(option code M1)
The integral digital display can toggle between: level, distance, volume, internal temperature,
interface distance, interface level, peak amplitudes, interface thickness, percentage of range,
analog current out
Note
The display cannot be used for configuration purposes.
Remote Display
Data can be read from the optional integral display or remotely using the Rosemount 751 Field
Signal Indicator for 4-20 mA / HART (see Product Data Sheet, document number
00813-0100-4378), or the Rosemount 752 Remote Indicator for F
OUNDATION fieldbus (see
Product Data Sheet, document number 00813-0100-4377).
Configuration Tools
HART: Rosemount Radar Master, Emerson
®
Field Communicator, AMS Device Manager, or any
other DD (Device Description) compatible host system
FOUNDATION fieldbus: Rosemount Radar Master, Emerson Field Communicator, DeltaV, or any
other DD (Device Description) compatible host system
DTM (compliant with version 1.2 of the FDT/DTM specification) supporting configuration in for
instance Yokogawa Fieldmate/PRM, E+H™ FieldCare, and PactWare
Output Units
Level, Interface and Distance: ft, inches, m, cm, or mm
Level Rate: ft/s, m/s, in./min, m/h
Volume: ft
3
, inch
3
, US gals, Imp gals, barrels, yd
3
, m
3
, or liters
Temperature: °F and °C
Output Variables
Damping 0-60 s (2 s, default value)
5301 5302 5303 PV, SV, TV, QV
Level XXX X
Distance to Level (Ullage) X X X X
Level Rate XXX X
Signal Strength XXX X
Volume XXX X
Internal TemperatureXXX X
Interface Level (X)
(1)
XN/A X
Interface Distance (X)
(1)
XN/A X
Interface Level Rate (X)
(1)
XN/A X
Interface Signal Strength (X)
(1)
XN/A X
Upper Layer Thickness (X)
(1)
XN/A X
Lower Volume (X)
(1)
XN/A X
Upper Volume (X)
(1)
XN/A X
Signal Quality X X X (X)
(2)
Surface/Noise Margin X X X (X)
(2)
Vapor DC X N/A N/A (X)
(2)
Analog Output Current
(3)
XXXN/A
% of Range
(4)
XXXN/A
(1) Interface measurement only for fully submerged probe, see page 34
(2) Not available as primary variable
(3) LCD display variable only. Not available for F
OUNDATION fieldbus, Modbus Signal
Output, or for HART units in fixed current mode
(4) LCD display variable only. Not available for F
OUNDATION fieldbus Signal Output
