03300-1656-5003 3-in. Centering Disc (5 pcs), PTFE, Segmented Rigid Single Lead 2.7 in. (68 mm)
03300-1656-5004 4-in. Centering Disc (5 pcs), PTFE, Segmented Rigid Single Lead 3.6 in. (92 mm)
03300-1656-5006 6-in. Centering Disc (5 pcs), PTFE, Segmented Rigid Single Lead 5.55 in. (141 mm)
03300-1656-5008 8-in. Centering Disc (5 pcs), PTFE, Segmented Rigid Single Lead 7.40 in. (188 mm)
Segmented rigid single lead probe spare part kit
03300-0050-0001 15.2 in. / 385 mm Segment for Top connection (1 pc)
03300-0050-0002 31.5 in. / 800 mm Segment (1 pc)
03300-0050-0003 31.5 in. / 800 mm Segment (3 pcs)
03300-0050-0004 31.5 in. / 800 mm Segment (5 pcs)
03300-0050-0005 31.5 in. / 800 mm Segment (12 pcs)
Vented flanges
(3)
03300-1812-0092 Fisher 249B, 259B
03300-1812-0093 Fisher 249C
03300-1812-0091 Masoneilan
Flushing connection rings
DP0002-2111-S6 2 in. ANSI, ¼ in. NPT connection
DP0002-3111-S6 3 in. ANSI, ¼ in. NPT connection
DP0002-4111-S6 4 in. ANSI, ¼ in. NPT connection
DP0002-5111-S6 DN50, ¼ in. NPT connection
DP0002-8111-S6 DN80, ¼ in. NPT connection
HART modem and cables
03300-7004-0001 MACTek Viator HART Modem and cables (RS232 connection)
★
03300-7004-0002 MACTek Viator HART Modem and cables (USB connection)
★
Remote housing mounting spare part kit
03300-7006-0001 1 m / 3.2 ft. Remote Housing Mounting Cable and Bracket
03300-7006-0002 2 m / 6.5 ft. Remote Housing Mounting Cable and Bracket
03300-7006-0003 3 m / 9.8 ft. Remote Housing Mounting Cable and Bracket
Verification reflector (high level supervision) spare part kit (requires 5300 firmware version 2.H0 or later)
05300-7200-0001 For 3” to 8” pipe/chamber (inner diameter)
05300-7200-0002 For tanks or 10” pipe/chamber (inner diameter) or wider
(1) If a centering disc is required for a flanged probe, the centering disc can be ordered with options Sx or Px on page 13 in the model code. If a centering disc is
required for a threaded connection, or as a spare part, it should be ordered using the item numbers listed below.
(2) To order a centering disc in a different material consult the factory.
(3) 1-½ in. NPT threaded connection (RA) is required.
Table 3. Accessories Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
