Engineered solutions (see page 50)
Rxxxx Engineered Solutions beyond standard model codes. (Consult factory for details)
Example model string: 5303-H-A-1-S-1-V-6A-M-025-50-AA-I1-M1C1.
E-025-05, means 25 ft and 5 in. probe length. M-025-50, means 25.5 m.
(1) Not available with Flame/Explosion-proof approvals (E1, E3, E5, E6, E7, KA, KB, KC, and KD)
(2) Process seal rating. Final rating depends on flange and O-ring selection. See “Temperature and pressure limits” on page 30-33.
(3) For other materials, consult the factory.
(4) 0.79 lb (0.36 kg) standard weight for flexible single lead probe. L=5.5 in. (140 mm).
(5) Extra length for fastening is added in the factory.
(6) 1.2 lb (0.56 kg) standard weight for flexible single lead probe. L=5.5 in. (140 mm).
(7) Probe weight included if applicable. Give the total probe length in feet and inches or meters and centimeters, depending on selected probe length unit.
If tank height is unknown, please round up to an even length when ordering. Probes can be cut to exact length in field. Maximum allowable length is deter-
mined by process conditions. See “Total Probe Length” on page 48 for more probe length guidance.
(8) Available in 316L SST. For other materials, consult the factory.
(9) Available in 316L and EN 1.4404. For other materials consult the factory.
(10) Requires F
OUNDATION fieldbus signal output (U
i
parameter listed in “Product Certifications” on page 55).
(11) Available for tank connection with flange.
(12) The standard alarm setting is high.
(13) Certificate includes all pressure retaining wetted parts.
(14) Can not be combined with E2 (INMETRO Flameproof) or I2 (INMETRO Intrinsic Safety).
Table 2. 5303 Level for Solids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
