Rosemount 5300 Series
October 2014
Options
Display
M1 Integral digital display
★
Communication
HR7
4–20 mA with digital signal based on HART 7 protocol.
Only available with HART 4-20 mA output (output code H). (consult factory for details)
★
Hydrostatic testing
P1 Hydrostatic testing
(11)
★
Transient protection
T1
Transient Protection Terminal Block. Selectable with HART 4-20 mA output (output code H). Already included in
all F
OUNDATION fieldbus variations.
★
Installation options
LS
Long stud 9.8 in (250 mm) for flexible single lead probe to prevent contact with wall/nozzle.
Standard length is 3.9 in (100 mm) for probes 5A and 5B; 5.9 in. (150 mm) for probes 6A and 6B
★
BR Mounting Bracket for 1½-in. NPT Process Connection (RA) (see page 75)
Special configuration (software)
C1 Factory configuration (Configuration Data Sheet required with order, available at www.rosemount.com)
★
C4 Namur alarm and saturation levels, high alarm
★
C5 Namur alarm and saturation levels, low alarm
★
C8 Low alarm
(12)
(standard Rosemount alarm and saturation levels)
★
Special certifications
Q4 Calibration Data Certification
★
Q8 Material Traceability Certification per EN 10204 3.1
(13)
★
QS Prior-use certificate of FMEDA Data. Only available with HART 4-20 mA output (output code H).
★
QT
Safety-certified to IEC 61508 with certificate of FMEDA data.
Only available with HART 4-20 mA output (output code H).
★
U1 WHG Overfill Approval
(14)
. Only available with HART 4-20 mA output (output code H)
★
QG GOST Primary Verification Certificate
Diagnostic functionality
D01 FOUNDATION fieldbus Diagnostics Suite (includes Signal Quality Metrics diagnostics)
★
DA1 HART Diagnostics Suite (includes Signal Quality Metrics diagnostics)
★
Remote housing mounting (see page 76)
B1 1m / 3.2 ft. Remote Housing Mounting Cable and Bracket
B2 2m / 6.5 ft. Remote Housing Mounting Cable and Bracket
B3 3m / 9.8 ft. Remote Housing Mounting Cable and Bracket
Table 2. 5303 Level for Solids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
