Product data

17
www.rosemount.com
Rosemount 5300 Series
October 2014
JA DN100, PN16
★
JB DN100, PN40
★
HI DN50, PN40, EN 1092-1 Type E spigot face (DIN 2513 Form V13)
HP DN50, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F)
HQ DN50, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F)
IH DN80, PN16, EN 1092-1 Type E spigot face (DIN 2513 Form V13)
II DN80, PN40, EN 1092-1 Type E spigot face (DIN 2513 Form V13)
IP DN80, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F)
IQ DN80, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F)
JH DN100, PN16, EN 1092-1 Type E spigot face (DIN 2513 Form V13)
JI DN100, PN40, Type E spigot face (DIN 2513 Form V13)
JP DN100, PN16, EN 1092-1 Type C tongue face (DIN 2512 Form F)
JQ DN100, PN40, EN 1092-1 Type C tongue face (DIN 2512 Form F)
KA DN150, PN16
JIS flanges
(9)
UA 50A, 10K
★
VA 80A, 10K
★
XA 100A, 10K
★
UB 50A, 20K
VB 80A, 20K
XB 100A, 20K
YA 150A, 10K
YB 150A, 20K
ZA 200A, 10K
ZB 200A, 20K
Threaded connections
(8)
Probe type
RA 1½-in. NPT thread All
★
RC 2-in. NPT thread All
★
RB 1-in. NPT thread All
SA 1½-in. BSP (G 1½-in.) thread All
SB 1-in. BSP (G 1-in.) thread All
Hazardous locations certifications (see page 55-60)
NA No Hazardous Locations Certifications
★
E1 ATEX Flameproof
★
Table 2. 5303 Level for Solids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
