Product data

16
www.rosemount.com
Rosemount 5300 Series
October 2014
Material of construction
(3)
: process connection / probe Probe type
1 316L SST (EN 1.4404) All
★
Sealing, o-ring material (consult factory for other o-ring materials)
VViton
®
Fluoroelastomer
★
E Ethylene Propylene (EPDM)
★
KKalrez
®
6375 Perfluoroelastomer
★
B Nitrile Butadiene (NBR)
★
Probe type Process connection Probe lengths
5A Flexible Single Lead with weight, 4 mm
(4)
Flange /
1-in., 1½-in., 2-in. Thread
Min: 3 ft 4 in. (1 m)
Max: 115 ft. (35 m)
★
5B Flexible Single Lead with chuck, 4 mm
(5)
Flange /
1-in., 1½-in., 2-in. Thread
Min: 3 ft 4 in. (1 m)
Max: 115 ft. (35 m)
★
6A Flexible Single Lead with weight, 6 mm
(6)
Flange /
1-in., 1½-in., 2-in. Thread
Min: 3 ft 4 in. (1 m)
Max: 164 ft. (50 m)
★
6B Flexible Single Lead with chuck, 6 mm
(5)
Flange /
1-in., 1½-in., 2-in. Thread
Min: 3 ft 4 in. (1 m)
Max: 164 ft. (50 m)
★
Probe length units
E English (feet, in.)
★
M Metric (meters, centimeters)
★
Total probe length
(7)
(feet/m)
XXX 0-164 ft or 0-50 m
★
Total probe length
(7)
(in./cm)
XX 0-11 in. or 0-99 cm
★
Process connection - size / type (consult the factory for other process connections)
ASME / ANSI flanges
(8)
AA 2 in., 150 lb
★
AB 2 in., 300 lb
★
BA 3 in., 150 lb
★
BB 3 in., 300 lb
★
CA 4 in., 150 lb
★
CB 4 in., 300 lb
★
DA 6 in., 150 lb
EN (DIN) flanges
(9)
HB DN50, PN40
★
IA DN80, PN16
★
IB DN80, PN40
★
Table 2. 5303 Level for Solids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
