(1) Not available with Flame/Explosion-proof approvals (E1, E3, E5, E6, E7, KA, KB, KC, and KD)
(2) Process seal rating. Final rating depends on flange and O-ring selection. See “Temperature and pressure limits” on page 30-33.
(3) Requires option None for sealing (no O-ring).
(4) Welding Procedure Qualification Record Documentation will be supplied.
(5) For other materials, consult the factory.
(6) Consult the factory for this option.
(7) Requires Operating Temperature and Pressure code H, P, or C.
(8) Only available with Operating Temperature and Pressure code S.
(9) Available with Material of Construction codes 1 and D. Consult the factory for other materials.
(10) Only available with Operating Temperature and Pressure code H.
(11) 0.79 lb (0.36 kg) standard weight for flexible single lead probe. L=5.5 in. (140 mm).
For PTFE covered probes: 2.2 lb (1 kg) standard weight for flexible single lead probe. L=17.1 in. (434 mm).
(12) Extra length for fastening is added in factory.
(13) Requires model 5301.
(14) Probe weight included if applicable. Give the total probe length in feet and inches or meters and centimeters, depending on selected probe length unit.
If tank height is unknown, please round up to an even length when ordering. Probes can be cut to exact length in field. Maximum allowable length is
determined by process conditions. See “Total Probe Length” on page 48 for more probe length guidance.
(15) Available in 316L SST. For other materials consult the factory.
(16) Raised face type for SST flanges up to class 1500.
(17) Available in 316L and EN 1.4404. For other materials consult the factory.
(18) Type A flat face for SST flanges up to PN100 and type B2 raised face for SST flanges PN160 and PN250.
(19) Raised face type for SST flanges.
(20) Probes are intrinsically safe.
(21) Requires F
OUNDATION fieldbus signal output (U
i
parameter listed in “Product Certifications” on page 55).
(22) Available for tank connection with flange.
(23) For Probe Type 3A, 3B, 4A, 4B, 4S, and 4U, and PTFE-coated 5A.
(24) Not available with PTFE covered probes.
(25) Only for Material of Construction code 1 and 3. For other materials, consult the factory.
(26) The standard alarm setting is high.
(27) Certificate includes all pressure retaining wetted parts.
(28) Not available for Dynamic Vapor Compensation probes (type 3V, 4U) or the Verification Reflector options (HL1, HL2, HL3).
(29) Can not be combined with E2 (INMETRO Flameproof) or I2 (INMETRO Intrinsic Safety).
(30) Only for Housing Material code S and Operating Temperature and Pressure code S.
(31) Only available with HART 4-20 mA output (code H), standard operating temperature and pressure (code S), material of construction code 1, and flexible single
lead probes (probe type 5A or 5B). Not available with option codes QS and QT, and remote housing mounting (option code B1, B2, or B3).
(32) Available for SST, Alloy C-276, Alloy 400, and Duplex 2205 probes, type 2A, 4A, 4B, 4S, and 5A. Same disc material as probe material. For more information, see
“Centering Discs” on page 52.
(33) Available for probe types 2A, 4A, 4B, 4S, and 5A. Not available with Operating Temperature and Pressure code H or Material of Construction codes 7 and 8.
(34) Selecting the XC option code on the 5300 Guided Wave Radar and the 9901 Chamber will result in matching, consolidating, configuring, and shipping of the
two products in one crate. Note that the flange bolts are only hand-tightened. Long rigid single lead probes (>8 ft/2.5 m) are shipped separately in order to
reduce transportation risk damage.
