Product data

12
www.rosemount.com
Rosemount 5300 Series
October 2014
Materials certification
N2 NACE material recommendation per ANSI/NACE MR0175/ISO 15156 and MR0103
(23)
★
Transient protection
T1
Transient Protection Terminal Block. Selectable with HART 4-20 mA output (output code H). Already included in
all F
OUNDATION fieldbus variations.
★
Installation options
LS
Long stud
(24)
9.8 in (250 mm) for flexible single lead probe to prevent contact with wall/nozzle.
Standard length is 3.9 in (100 mm) for probes 5A and 5B.
★
BR Mounting Bracket for 1½-in. NPT Process Connection (RA) (see page 75)
Weight and anchoring options for flexible single probes (probe type 5A)
W3
Heavy weight (recommended choice for most applications)
Weight=2.43 lb (1.10 kg), Length=5.5 in. (140 mm), Diameter=1.5 in. (37.5 mm)
★
W2
Short weight (when measuring close to the probe end)
(25)
Weight=0.88 lb (0.40 kg. Length=2 in. (50 mm), Diameter=1.5 in. (37.5 mm)
Special configuration (software)
C1 Factory configuration (Configuration Data Sheet required with order, available at www.rosemount.com)
★
C4 Namur alarm and saturation levels, high alarm
★
C5 Namur alarm and saturation levels, low alarm
★
C8 Low alarm
(26)
(standard Rosemount alarm and saturation levels)
★
Special certifications
Q4 Calibration Data Certification
★
Q8 Material Traceability Certification per EN 10204 3.1
(27)
★
QS Prior-use certificate of FMEDA Data. Only available with HART 4-20 mA output (output code H).
★
QT
Safety-certified to IEC 61508 with certificate of FMEDA data. Only available with HART 4-20 mA output (output
code H).
(28)
★
U1 WHG Overfill Approval
(29)
. Only available with HART 4-20 mA output (output code H)
★
QG GOST Primary Verification Certificate
Q66 Welding Procedure Qualification Record Documentation
Marine / shipboard approvals
(30)
SBS American Bureau of Shipping Type Approval (consult factory for details)
SDN Det Norske Veritas (DNV) Type Approval (consult factory for details)
SLL Lloyd's Register Type Approval (consult factory for details)
SBV Bureau Veritas Type Approval (consult factory for details)
SRS Russian Maritime Register of Shipping Type Approval (consult factory for details)
SGL Germanischer Lloyd Type Approval (consult factory for details)
Table 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information
The starred options (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject
to additional delivery lead time.
