80 Programming ViewPoint Wireless Touch Panels
Shorthand Send_Commands (Cont.)
Command Description
"'@CTN'
,<variable text
address>,<color_
number>"
Set the ON feedback text color to the specified color only if the
specified background color is not the same as the current
color.
variable text address = 1 - 255
color number = see Figure 92
Example:
SEND_COMMAND TP,"'@CTN’,1,72"
Sets the ON feedback text color to White for variable text but-
ton 1.
"'@IDF'"
Query the touch panel to return a string with the MS-DOS file-
name of the touch panel.
Example:
SEND_COMMAND TP,"'@IDF'"
The touch panel returns its MS-DOS file name in a string.
"'@IDP'"
Query the touch panel to return a string with the TPDesign3
project name.
Example:
SEND_COMMAND TP,"'@IDP'"
The touch panel returns a string that contains its TPDesign3
project name.
"'@ILEV <joystick axis
to invert'"
Invert the joystick axis.
Example:
SEND_COMMAND TP,"'@ILEV 3'"
Invert the joystick axis to move the origin to another corner.
• Normal G3 Joystick (origin: top left) 0
• Invert Horizontal Axis (origin: top right) 1
• Invert Vertical Axis (origin: bottom left) 2
• Invert Both Axes (origin: bottom right) 3
