68 Programming ViewPoint Wireless Touch Panels
Serial Commands (Cont.)
Command Description
"HELLO"
Verify that the serial communication.
Example:
"HELLO"
If the communication is active and working, the response
would be “How are you doing?”.
“LZAP!”
Clear all low-level memory and erase IR codes.
Example:
”LZAP!”
Clears all IR codes from the panel.
"SETUP"
Go to the Setup page.
Example:
"SETUP"
Flips the touch panel to the Setup page.
"VER"
Restore current version.
Example:
"VER"
This returns the current version of the main firmware.
"ZAP!"
Clear all memory and erase buttons, pages, drawings, and
symbols.
Example:
"ZAP!"
Clears all memory and erases all buttons, pages, drawings,
and symbols.
Note
Commands such as LZAP!
and ZAP! Can be used as
both Serial Commands and
Send_Commands.
