Instruction manual

36 Designing Touch Panel Pages ViewPoint Wireless Touch Panels
5. Enter a channel value of 1 through 255 in the keypad. The programming soft-
ware uses the channel code number to identify the button and its operations.
6. Press ENTER to store the channel number into memory, close the keypad, and
return to the Button Properties page.
Setting the page flip
1. Press the left PAGE FLIP box in the Button Properties page (Figure 45) to open
the Page Flip Type list (Figure 46).
2. Press FLIP STANDARD to select a standard page flip.
3. Press the right PAGE FLIP box (Figure 45) to open the PAGE FLIP TYPE menu
(Figure 46).
4. Press the right FLIP to Page to open a list of all the touch panel pages stored into
memory. If the desired page is not present in the PAGE flip destination menu
(Figure 47), check to verify that the page has been saved.
Note
The channel codes for non-
active buttons are 0, and ac-
tive buttons is 1 through 255.
Figure 45
Page FLIP boxes
Figure 46
PAGE FLIP TYPE menu
Note
When selecting FLIP
PREVIOUS in the Page FLIP
type button, the PAGE menu
ap
pears.
Page Flip Type button
Flip to Page button
