ViewPoint Wireless Touch Panels Product Pics and Specs 9
ViewPort Docking Station Specifications
Figure 7 lists the specifications for the VPA-DS ViewPort Docking Station.
ViewPort specifications
Dimensions (HWD) 4.83" x 8.26" x 7.62" (122.7 mm x 209.8 mm x 193.4 mm)
Environmental operating range:
Temperature 50 °F to 95 °F (10 °C to 35 °C)
Humidity 0% to 95% non-condensing
Power requirement 12 VDC at 1.5 amp
Indicators:
Yellow LED Indicates ViewPoint connected to ViewPort Docking Station
Green LED Indicates spare battery is fully charged
Red LED Indicates spare battery is charging
Options:
Power supply ViewPoint 12 VDC @ 1.5 amp power supply
Battery VPA-BP ViewPoint Rechargeable Battery (NiMH, 7.2 VDC
@ 3.7 Amp hours)
Figure 7
ViewPort specifications
