Instruction manual
Table Of Contents
- ViewPoint Wireless Touch Panels
- Introduction
- Product Pics and Specs
- Connections, Cleaning, and Charging
- Touch Panel Basics
- Designing Touch Panel Pages
- Overview
- Activating the Edit button
- Setting the Device Base
- Setting the Device Used
- Creating a Page
- Creating a Button
- Button Properties
- Using TPDesign3 to Download Bitmaps, Icons, and Fonts
- Button Properties for External Pushbuttons
- Creating an IR Macro Button
- Creating a Joystick
- Creating a Bargraph
- Linking the New Page to the Main Page
- Exiting Edit Mode
- Programming
- Overview
- PC to ViewPoint Connections
- Programming the ViewPoint
- Programming Changes
- Serial Commands
- System Send_Commands
- Gray Scale and Programming Numbers
- Colors/Shades of Gray and Programming Numbers
- Font Styles and Programming Numbers
- Border Styles and Programming Numbers
- Shorthand Send Commands
- Color/Gray Scale Send_Commands
- Variable Text Send_Commands
- Shorthand Variable Text Commands
- Buttons String Commands
- Button IR Macro Commands
- Loading Infrared (IR) Files
- Upgrading the Firmware
- Contacting Sales and Technical Support
- Index
8 Product Pics and Specs ViewPoint Wireless Touch Panels
Battery Specifications
Figure 5 shows the specifications for the VPA-BP ViewPoint rechargeable battery.
Battery specifications
Battery voltage
Type
Amp hour (Ah)
Weight
Dimensions
7.2 VDC
Rechargeable nickel metal hydride (NiMH)
6-cell NiMH, 3.7 Ah minimum
11.7 oz (331.7 g)
5.34" x 2.02" x 0.69" (136 mm x 51 mm x 17.5 mm)
VPA-DS ViewPort Docking Station
The ViewPort Docking Station (Figure 6) includes a built-in battery charger and an
angled desktop docking station to cradle your ViewPoint touch panel.
Figure 5
Battery specific
ations
Figure 6
ViewPort Docking Station
