Instruction manual
Table Of Contents
- ViewPoint Wireless Touch Panels
- Introduction
- Product Pics and Specs
- Connections, Cleaning, and Charging
- Touch Panel Basics
- Designing Touch Panel Pages
- Overview
- Activating the Edit button
- Setting the Device Base
- Setting the Device Used
- Creating a Page
- Creating a Button
- Button Properties
- Using TPDesign3 to Download Bitmaps, Icons, and Fonts
- Button Properties for External Pushbuttons
- Creating an IR Macro Button
- Creating a Joystick
- Creating a Bargraph
- Linking the New Page to the Main Page
- Exiting Edit Mode
- Programming
- Overview
- PC to ViewPoint Connections
- Programming the ViewPoint
- Programming Changes
- Serial Commands
- System Send_Commands
- Gray Scale and Programming Numbers
- Colors/Shades of Gray and Programming Numbers
- Font Styles and Programming Numbers
- Border Styles and Programming Numbers
- Shorthand Send Commands
- Color/Gray Scale Send_Commands
- Variable Text Send_Commands
- Shorthand Variable Text Commands
- Buttons String Commands
- Button IR Macro Commands
- Loading Infrared (IR) Files
- Upgrading the Firmware
- Contacting Sales and Technical Support
- Index
ViewPoint Wireless Touch Panels Product Pics and Specs 7
ViewPoint specifications (Cont.)
Assignable devices:
VPT-CP/VPT-GS
ViewPoint RF
AMX IR
IR other than AMX
VPN-CP/VPN-GS
Device ID
Group ID
ViewPoint
IR
Device 1
Device 1
Device 2, 3, and/or 4
0-255
0-16
Device 1, 2, 3, and/or 4
Device 2, 3, and/or 4
Accessories:
VPA-BP
Power supply
ViewPoint Rechargeable Battery
12 VDC, 1500 mA
Optional Accessories:
VPA-BP
VPA-CHG
Power Supply
AXR-RF
AXR-NWS
ViewPoint Rechargeable Battery
Fast-Cycle Battery Charger for VPA-BP
12 VDC, 1500 mA
RF Receiver (VPT-CP/VPT-GS only)
NetWave Server (VPN-CP/VPN-GS only)
VPA-BP ViewPoint Rechargeable Battery
The ViewPoint Touch Panels use a VPA-BP rechargeable battery (Figure 4) that con-
sists of six rechargeable Nickel Metal Hydride (NiMH) cells.
Figure 4
VPA-BP ViewPoint Re-
chargeable Battery
