Instruction manual
Table Of Contents
- ViewPoint Wireless Touch Panels
- Introduction
- Product Pics and Specs
- Connections, Cleaning, and Charging
- Touch Panel Basics
- Designing Touch Panel Pages
- Overview
- Activating the Edit button
- Setting the Device Base
- Setting the Device Used
- Creating a Page
- Creating a Button
- Button Properties
- Using TPDesign3 to Download Bitmaps, Icons, and Fonts
- Button Properties for External Pushbuttons
- Creating an IR Macro Button
- Creating a Joystick
- Creating a Bargraph
- Linking the New Page to the Main Page
- Exiting Edit Mode
- Programming
- Overview
- PC to ViewPoint Connections
- Programming the ViewPoint
- Programming Changes
- Serial Commands
- System Send_Commands
- Gray Scale and Programming Numbers
- Colors/Shades of Gray and Programming Numbers
- Font Styles and Programming Numbers
- Border Styles and Programming Numbers
- Shorthand Send Commands
- Color/Gray Scale Send_Commands
- Variable Text Send_Commands
- Shorthand Variable Text Commands
- Buttons String Commands
- Button IR Macro Commands
- Loading Infrared (IR) Files
- Upgrading the Firmware
- Contacting Sales and Technical Support
- Index
ViewPoint Wireless Touch Panels Product Pics and Specs 5
Product Pics and Specs
Overview
If you like pictures, then this section is a great place to start learning about the View-
Point Touch Panels and its accessories. If you like low-level specifications, this section
is written for you, too. In addition to the pictures, you’ll find detailed descriptions
about the rechargeable battery, docking station, and also complete specifications like
product weights, dimensions, power ratings, etc.
ViewPoint Wireless Touch Panel
The ViewPoint Touch Panels (Figure 2) are hand-held, liquid crystal display (LCD)
control devices that elegantly integrate graphical control, wireless convenience, and
both desktop/hand-held operation. There are two series of panels; a Color-Passive
series that features a six-inch LCD with 256 colors, and a Grayscale series that fea-
tures a six-inch grayscale LCD with 16 shades of gray. Both come with direct access
buttons on each side that can be used for channel up/down and volume up/down
operations.
The ViewPoint Touch Panels are now available with either one-way RF or two-way
NetWave digital spread-spectrum wireless control.
Figure 2
ViewPoint Touch Panel
