Controller not Communicating or Communication LED TX / RX Not Blinking
• Verify the LP-PK cable or network cable is connected correctly.
• If you are using LP-PK verify that the correct communication port is selected.
• Verify the LRP Controller is addressed properly.
System Status LED 2 not On
• Verify power is connected to the LRP Controller. There should be LEDs illuminated.
• Verify there is at least 24 VAC present to the secondary of the transformer supplying power to the LRP Controller. Use
a voltmeter to check the power.
