Product Catalog Product Catalog
MODERO TOUCH PANELS Modero Touch Panels
THE AWARD-WINNING MODERO LINE OF TOUCH PANELS 17" MODERO WIDESCREEN TOUCH PANELS People noticed long ago that the evolution of technology progresses in leaps. In 2002, the world witnessed the future of control and automation with the introduction of the new Modero Touch Panels from AMX. It began with our award- winning 12" and 15" Moderos, which debuted at CEDIA EXPO 2002, and culminated with the 17" Modero Widescreen, presented at InfoComm 2003.
15" MODERO TOUCH PANELS The award-winning 15" Modero Touch Panels have taken the control industry by storm. Recognized as “the controlling force," the 15" Modero boasts features that remain unprecedented and unrivaled: A bright, easy-to-view display. Extremely sharp images. A rich 16-million color palette. Innovative 8-bit transparency. Amazing G4 graphics. An anti-glare touch overlay. An ultra-wide 170° viewing angle. A convenient, effortless tilt feature.
12" MODERO TOUCH PANELS The 12" Modero Touch Panels have enjoyed enormous success in the marketplace by offering a set of innovative features. At a price comparable to our previous generation of 10.4" panels, the 12" Modero remains one of our most popular to date. NXD-CV12 NXT-CV12 12" Flush Mount Video Touch Panel FG2251-12K 12" Table Top Video Touch Panel FG2250-11K NXD-CA12 NXT-CA12 12" Table Top Touch Panel FG2250 The 12" Modero Touch Panel delivers AMX performance and styling.
7" MODERO WIDESCREEN TOUCH PANEL Wider is better – and now the popular Modero Widescreen is available in a compact 7" model. If you desire extra on-screen real estate but your needs call for a smaller panel, the 7" Modero Widescreen is the perfect fit for any integrated environment. The Wall Mount version with it’s 7" wide screen provides more than enough space to display colorful and animated graphics and icons, to watch multiple windows, and to control a variety of audio/video equipment.
8.4" MODERO VIEWPOINT TOUCH PANELS The 8.4" Modero ViewPoint (MVP-8400) is the ultimate user interface, incorporating wireless mobility, Table Top functionality, and the flexibility to operate as a Wall/Flush Mount unit. The MVP-8400 also includes 1-way and 2-way communications capabilities and standard 802.11b wireless technology.
7.5" MODERO VIEWPOINT TOUCH PANELS The 7.5" Modero ViewPoint (MVP-7500) is the ultimate user interface, incorporating wireless mobility, Table Top functionality, and the flexibility to operate as a Wall/Flush Mount unit. The MVP-7500 also includes 1-way and 2-way communications capabilities and standard 802.11b wireless technology.
MODERO VIEWPOINT ACCESSORIES MVP-TDS MVP-WDS MVP Table Top Docking Station FG5965-10 MVP Wall/Flush Mount Docking Station FG5965-11 Place the wireless MVP into the Table Top Docking Station and re-charge its batteries while remaining in continuous control of your integrated technology. The adjustable station creates just the right viewing angle for any situation.
MODERO VIEWPOINT ACCESSORIES PS4.4 13.5 VDC, 4.4 Power Supply, (regulated 110/220 VAC input) FG423-44 MVP-KS MVP KickStand FG5965-12 The MVP KickStand, MVP-KS, is compatible with both the MVP-7500 and MVP-8400 Touch Panel. The MVP-KS allows the MVP to rest at an optimal viewing angle on any flat level surface. APPLICATION • DC POWER OUTPUT • • STANDARD FEATURES (PRELIMINARY SPECIFICATIONS SUBJECT TO CHANGE) DIMENSIONS (HWD) • 6.34" x 7.91" x 0.59" (16.10 cm x 20.10 cm x 1.50 cm) • • 13.
MODERO TOUCH PANEL ACCESSORIES NXA-BASE/B Battery Base Kit for Modero Touch Panels FG2255K NXA-AVB Audio/Video Breakout Box FG2254-01 The NXA-AVB Breakout Box comes standard with the Modero Color Video Touch Panels and is available as an option for Modero Color Active Touch Panels. The Breakout Box transfers audio/video signals from an outside source to and from the Modero Touch Panel. It can also be used for pass-through power and ICSNet connections.
MODERO TOUCH PANEL ACCESSORIES CB-TP17 NXT-CHG Conduit Box for NXD-CV17 FG034-10 Quick Charger Kit for Modero Touch Panels FG2250K CB-TP15 For added convenience, the NXT-BP Power Pack batteries can be quick-charged with the new NXT-CHG Modero Power Station. The Power Station is a two-slot, stand-alone unit that recharges up to two “smart" batteries, using sequential charging and recalibration techniques. Through sequential charging, the batteries placed in each slot are recharged one at a time.
TOUCH PANEL INTERFACE 4 A key to leading AMX technology has been the amazing G4 (4th Generation Graphics) engine introduced on the Touch Panel Interface 4. Unmatched G4 features are the gold standard for high-end user interface designs and capabilities. TOUCH DRIVERS: • NetLinx Touch Panel Interface 4 FG2275 FRONT PANEL COMPONENTS: • • Create a Touch Panel user interface that combines video and RGB media with Touch Panel graphics.
TPI/4 ACCESSORIES TP4-RGBCBL RGB Breakout Cable, 15 Pin Female FG2275-30 NXA-CFTPI128M 128MB Compact Flash Upgrade for TPI/4 FG2116-12 NXA-CFTPI256M 256MB Compact Flash Upgrade for TPI/4 FG2116-13 NXA-CFTPI512M 512MB Compact Flash Upgrade for TPI/4 FG2116-14 NXA-CFTPI1G 1GB Compact Flash Upgrade for TPI/4 FG2116-15 NXA-EXM128M 128MB SDRAM Upgrade for TPI/4 FG079-01 NXA-EXM256M 256MB SDRAM Upgrade for TPI/4 FG079-02 CONFIDENTIAL INFORMATION © 2003 AMX Corporation. All rights reserved.
VIEWPOINT WIRELESS TOUCH PANELS ViewPoint Wireless Touch Panels
8.4" MODERO VIEWPOINT TOUCH PANELS The 8.4" Modero ViewPoint (MVP-8400) is the ultimate user interface, incorporating wireless mobility, Table Top functionality, and the flexibility to operate as a Wall/Flush Mount unit. The MVP-8400 also includes 1-way and 2-way communications capabilities and standard 802.11b wireless technology.
7.5" MODERO VIEWPOINT TOUCH PANELS The 7.5" Modero ViewPoint (MVP-7500) is the ultimate user interface, incorporating wireless mobility, Table Top functionality, and the flexibility to operate as a Wall/Flush Mount unit. The MVP-7500 also includes 1-way and 2-way communications capabilities and standard 802.11b wireless technology.
MODERO VIEWPOINT ACCESSORIES MVP-TDS MVP-WDS MVP Table Top Docking Station FG5965-10 MVP Wall/Flush Mount Docking Station FG5965-11 Place the wireless MVP into the Table Top Docking Station and re-charge its batteries while remaining in continuous control of your integrated technology. The adjustable station creates just the right viewing angle for any situation.
MODERO VIEWPOINT ACCESSORIES PS4.4 MVP-KS MVP KickStand FG5965-12 The MVP KickStand, MVP-KS, is compatible with both the MVP-7500 and MVP-8400 Touch Panel. The MVP-KS allows the MVP to rest at an optimal viewing angle on any flat level surface. 13.5 VDC, 4.4 Power Supply, (regulated 110/220 VAC input) FG423-44 APPLICATION • DC power for MVP-7500, MVP-8400 and MVP-TDS DC POWER OUTPUT • • • 13.5 Volts DC, 4.
VIEWPOINT TOUCH PANELS Wireless ViewPoint Touch Panels are an elegant integration of graphic control, wireless convenience, timeless styling and low-cost practicality. The 1-way and 2-way ViewPoint panels are designed for both desktop and hand-held operation.
VIEWPOINT TOUCH PANEL ACCESSORIES VPA-DS VPA-BP ViewPort Docking Station FG5961-02 ViewPoint Rechargeable Battery (NiMH) FG0962 Cradles ViewPoint Touch Panel at perfect angle for Table Top control. BATTERY: FEATURES • • • Charges ViewPoint’s internal battery fully within two hours Stores spare VPA-BP battery pack; charges battery when ViewPoint is not present in cradle LED INDICATORS • • • • Approx. 6 hours full-bright run time (1-way wireless) DIMENSIONS (HWD): 5.3" x 2.0" x 0.
G3 TOUCH PANELS G3 Touch Panels
10.4" COLOR GRAPHIC ACTIVE TOUCH PANELS Size and functionality make the 10.4" Touch Panel one of the most universally accepted user interfaces in the industry. Sleek and unobtrusive, it fits into any decor and accommodates all the controls needed for a system of any size. *LIMITED AVAILABILITY* *LIMITED AVAILABILITY* AXD-CG10/PB AXT-CG10 Color Graphic Flush Mount, External Push Buttons, Black FG952-91 10.4" Color Graphic Table Top Touch Panel FG950-60 • Screen tilts for best viewing angle • 10.
10.4" COLOR VIDEO ACTIVE TOUCH PANELS The 10.4" Touch Panels from AMX are still some of the most popular user interfaces in the control industry. AXD-CV10/PB 10.4" Color Video Flush Mount Touch Panel, External Buttons FG952-81 AXT-CV10 10.4" Color Video Table Top Touch Panel FG950-40 • Screen tilts for best viewing angle • 10.
10.4" COLOR ACTIVE TOUCH PANELS The 10.4" Touch Panels from AMX are still some of the most popular user interfaces in the control industry. *LIMITED AVAILABILITY* AXT-CA10 *LIMITED AVAILABILITY* 10.4" Color Active Touch Panel FG950-30 The 10.4" Touch Panels from AMX are still some of the most popular user interfaces in the control industry. • Screen tilts for best viewing angle • 10.
G3 TOUCH PANEL ACCESSORIES CB-TP3 TP3 Conduit Box FG025-10 APPLICATIONS: • AXD-CG and AXD-CG/PB • AXD-CV and AXD-CV/PB • AXD-CA and AXD-CA/PB EXM-1MB 1MB Extended Memory FG074 CONFIDENTIAL INFORMATION © 2003 AMX Corporation. All rights reserved. AMX and the AMX logo are all trademarks of AMX Corporation. AMX reserves the right to alter specifications without notice at any time. AMX does not assume responsibility for any errors or omissions.
6" COLOR ACTIVE VIDEO TOUCH PANELS AC-CV6T Table Top Enclosure (Accessory) FG5924-20 Dark Gray FG5924-21 Platinum FG5924-22 Unfinished Aluminum AXD-CV6 6" Color Active Video Flush Mount Touch Panel FG5924-10 White FG5924-11 Black Like to see the video you’re controlling? Looking for the perfect panel for the wall or lectern? You’ll love the CV6 6" Color Active Video Flush Mount Touch Panel.
5.5" COLOR PASSIVE TOUCH PANELS AXD-MCP 5.5" Color Flush Mount Touch Panel FG925-40 White FG925-60 Black FG925-80 Ivory AXT-MCP 5.5" Color Passive Touch Panel FG925-20 Big control capabilities in a compact size. The AXT-MCP 5.5" Color Passive Touch Panel, boasts a vibrant color passive-matrix LCD, high resolution graphics, a rich color background and an adjustable console for the best viewing angle and ease of operation.
5.5" COLOR PASSIVE TOUCH PANELS AXD-MCP/PB 5.5" Color Flush Mount Touch Panel with External Pushbuttons FG925-41 White FG925-61 Black FG925-81 Ivory The 5.5" Color Flush Mount Touch Panel contains a mini 256 color passive-matrix LCD. The self-contained enclosure uses a microprocessor to control a wide range of multi-media equipment. Using the TPDesign3 software, you can create custom control and display pages with buttons, icons, sliders, bargraphs, time displays, logos and drawings. AXM-MCP 5.
5.5" COLOR PASSIVE TOUCH PANELS AXM-MCP/PB 5.5" Rack-Mount Color Touch Panel with External Pushbuttons FG925-91 Black CB-MTP MTP Conduit box FG027-10 APPLICATIONS • • Mounts in a wall, lectern, or any flat surface • • AXD-MLC and AXD-MLC/PB AXD-MCV and AXD-MCV/PB AXD-MCP and AXD-MCP/PB • Available with a black faceplate • Available with pushbuttons (MCP/PB) or without pushbuttons (MCP) LCD • • • 5.5" color passive-matrix LCD with a resolution of 320x240 pixels Visible area: 5 inches (12.
4" COLOR PASSIVE TOUCH PANELS Redesigned and ready to deliver enhanced control capabilities, in a minimum of space, at a price well within your budget. The sleek AXD-CP4/A and AXT-CP4/A 4" Color Touch Panels boast numerous innovations: A microphone, speakers, an IR receiver and buttons with LED indicators. This panel fits in nicely with any décor and provides just the right amount of control and automation.
4" COLOR PASSIVE TOUCH PANELS OPERATING ENVIRONMENT • AXD-CP4/A 4" Color Flush Mount Touch Panel with Audio FG5921-20 Black FG5921-21 Almond FG5921-22 White SCREEN RESOLUTION • 320x240 pixels (HV) VIEWING ANGLE • • Horizontal viewing angle: -+50° Vertical viewing angle: -+50° Indoor operation at temperatures between 10° C (50° F) to 40° C (104° F) and a humidity range of 5% to 90% RH (non-condensing) MEMORY • 512KB of SRAM and 2MB of Flash for a total memory of 2.
4" COLOR PASSIVE TOUCH PANELS *LIMITED AVAILABILITY* *LIMITED AVAILABILITY* AXT-CP4 AXD-CP4 4" Color Table Top Touch Panel FG5921-10 White FG5921-11 Black FG5921-12 Ivory 4" Color Flush Mount Touch Panel FG5921 White FG5921-01 Black FG5921-02 Ivory Need a touch of fun in your world? Choose the 4" Color Touch Panel and enjoy the wonders of smart, colorful control all within the absolute minimum space on your wall, table and budget.
TOUCH PANEL INTERFACE 3 This is where multi-media control capabilities in the control industry really started. Today, the Touch Panel Interface 3 remains the least expensive solution for incorporating multi-media into an AMX installation. AXB-TPI/3 TP3-RGB Touch Panel Interface 3 FG5975 TPI/3 RGB INPUT CARD FG5975-20 The TPI/3 sets the standard for multi-media touch control. Display simultaneously as many as three media windows, re-adjustable from thumbnails to full-screen view.
15" TOUCH MONITOR Many control applications call for multi-media capabilities of the user interface devices. Connect the Platinum Series 15" Touch Monitor to a Touch Panel Interface 4 and experience one of the most popular, feature-intensive AMX system solutions available.
15" MULTIMEDIA TOUCH MONITOR SYSTEMS It is our commitment to always go the extra mile for every AMX customer.
REMOTE CONTROLS Remote Controls
RECEIVERS AND TRANSMITTERS PC PRESENTER RECEIVERS PC PRESENTER SYSTEMS AXR-MSE Mouse and Keyboard Interface FG5508-315 315 MHz FG5508-418 418 MHz FG5508-433 433 MHz PC Presenter LP Laser Pointer Presenter System (no power supply) FG833-315 315 MHz Here's the ultimate PC presentation power tool. PC Presenter can act as a stand-alone system, offering wireless RF/IR mouse operation, keyboard control, onboard keyboard macro memory and optional laser pointer.
TXC+ REMOTES The TXC series of battery-operated, hand-held wireless transmitters features a microprocessor-based design for IR and RF transmission. Other radio frequencies are available on request. All offer switchable high-/low-frequency (455 kHz or 38 kHz) IR transmission. The TXC transmitters are available in 4- 16- and 32-pushbutton configurations with custom-engraved overlay and pushbutton layout, optional color text, color borders, and custom logo on panel overlay.
2-WAY WIRELESS RECEIVER AXR-IRSM+ Swivel Mount IR Receiver (AXLink) FG5454-01 *LIMITED AVAILABILITY* IR RECEPTION: Switchable for high-/low-frequency IR (455 kHz or 38 kHz) sensing AXR-NWS NetWave Server (NetWave 2-way 2.4 gHz RF, AXLink) FG5930-02 FEATURES • • INCLUDES: Screw slots for wall or ceiling mounting ENCLOSURE: Off-white metal with swivel mount DIMENSIONS (HWD): 2.0" x 3.3" x 2.6" (51 mm x 84 mm x 66 mm) WEIGHT: 4.
KEYPADS Keypads
KEYPADS SB KEYPADS DMS KEYPADS PLK-SB 1- and 2-Button Flush Mount Keypad FG2406-10 White Decora style FG2406-11 Black Decora style FG2406-12 Ivory Decora style PLK-DMS Direct Menu Select Keypad FG2405-01 White FG2405-02 Black FG2405-03 Ivory FG2405-04 Almond Displays multiple pages of menus under program control offering new control options, lists of CD titles, time, date, temperature and other applications.
WIRED KEYPADS AXD-MSP32 AXD-MSP8 Softwire 32-Button Keypad FG790-32 White FG790-33 Black FG790-34 Ivory Softwire 8-Button Keypad FG790-08 White FG790-09 Black FG790-12 Ivory The AXD-MSP8 Softwire 8-Button Keypad is a microprocessor-controlled pushbutton panel that fits into standard-gang wallplate enclosures. The AXM-MSP8 mounts in a standard 19" (482.6 mm) equipment rack and can be programmed to control a wide variety of equipment connected to an Axcess system.
WIRED KEYPADS PLK-MSP32 PLK-MSP8 Decor 32-Button Mini-Softwire Panel (3 bargraphs, 3 gang) PFG790-32 White Decora style (3 bargraph, 3 gang) PFG790-33 Black Decora style (3 bargraph, 3 gang) PFG790-34 Ivory Decora style (3 bargraph, 3 gang) Decor 8-Button Mini-Softwire Panel PFG790-08 White Decora style (1 bargraph, 1 gang) PFG790-09 Black Decora style (1 bargraph, 1 gang) PFG790-10 Ivory Decora style (1 bargraph, 1 gang) FEATURES • • • FEATURES Provides up to eight control buttons with LED feedback a
WIRED PANELS MINI-LCD PANELS AXM-MSP 32 AXP-MLCD Rack-Mount Mini-Softwire Panel Mini-LCD Panel FG514 FG792 PUSHBUTTONS: • Up to 32 pushbuttons (white, black, or gray) with LED feedback BARGRAPHS: • Three vertical 8-segment LED bargraphs ENCLOSURE: • 19.0" rack-mount; metal with black matte finish; two rack units high DISPLAY: Backlit 2-line 16-character per line LCD readout PUSHBUTTONS: Matrix of 20 pushbuttons under Lexan faceplate ENCLOSURE: Molded black matte plastic DIMENSIONS (HWD): 5.
CUSTOM PANEL INTERFACES AXP-AI8 NXP-CPI16 Analog 8-Input Board NetLinx Custom Panel Interface FG410 FG783 The NXP-CPI16 NetLinx Custom Panel Interface is a versatile device, useful for both custom panel and contact-closure applications. It will directly interface with AMX Touch Panels and components designed for integration with Axcess Control Systems.
CUSTOM PANEL INTERFACES AXP-CPIL LED Custom Panel Interface Board FG778 APPLICATION: • PC board for large LED lamped panels WPDR CONTROL PORTS: • One 8x8 switch/LED matrix and drivers for two bargraphs INCLUDES: • 34-pin header and 34-pin ribbon cable, 6.0' (1.8 m) DIMENSIONS (HWD): • SPDT Rocker Switch FG5620-20 White FG5620-21 Black FG5620-22 Ivory 3.5" x 3.1" x 0.9" (89 mm x 69 mm x 23 mm) WEIGHT: • 4.
NETLINX CONTROLLERS NetLinx Controllers
NETLINX NETLINX INTEGRATED CONTROLLERS AMX offers an innovative family of control products called the NI Series, combining the proven technology of the NetLinx Integrated Controller with the NetLinx ME260 Master Card into a single integrated control system. No other system compares to NetLinx, which simultaneously communicates over the AXLink databus, high-speed ICSNet control network, long distance ICSHub system link, Ethernet-driven computer networks and the TCIP/IP world of the Internet.
NETLINX INTEGRATED CONTROLLERS NXI NI-4000 NetLinx Integrated Controller (Controller only) FG2101 NetLinx Integrated Controller FG2105 Superior Functionality – The NI-4000 is geared to meet the high-end control and automation requirements within the most sophisticated and complex commercial and residential installations.
NETLINX MASTER CARD, CARDFRAME AND MODULES NXF NXC-ME260 NetLinx Master260 Card, Ethernet FG2010-60 The NXC-ME260 NetLinx Master260 Card installs into the NetLinx CardFrame, Integrated Controller and Modules.
NETLINX MASTER CARD, CARDFRAME AND MODULES NXF-MINI NetLinx Mini-CardFrame (CardFrame Only) FG2104 The NXF-MINI NetLinx Mini-CardFrame extends the control capabilities of the AMX NetLinx Control System to a remote area or location. Compatible with the ME260 Master Card, NI-2000, NI-3000 and NI-4000 NetLinx Controllers, the Mini-CardFrame allows the installer to add as many as four NetLinx devicespecific control cards for expanding control and automation features.
NETLINX CONTROL CARDS NetLinx Control Cards serve as flexible, modular building blocks for creating advanced control applications. Up to 12 Control Cards can be inserted into the NXF NetLinx CardFrame’s front-access control slots or supplied in an NXS-NMS NetModule Shell enclosure for stand-alone operation. NetLinx Control Cards can meet a wide variety of control needs, including multi-port RS-232/422/485, IR/Serial, Input/Output, Relay, Voltage, and Volume control.
NETLINX CONTROL CARDS NXC-VOL4 NXC-REL10 Volume Card, 4 Channels FG2024 Relay Card, 10 Channels FG2020 The NXC-VOL4 Volume Card provides four discrete volume control channels with LED feedback. The volume control channels can be programmed for mono or stereo operation, and balanced or unbalanced audio connections. It supports programmable audio levels, audio mute, variable ramp speeds and preset levels.
NETLINX HUB CARDS AND MODULES NXC-NH NetLinx ICSNet Hub Cards, NXC-HS NetLinx ICSHub Server Cards and NXC-HE NetLinx ICSHub Expander Cards are key components to comprehensive, far-reaching AMX control. These cards and modules are engineered to seamlessly distribute ICSP (Internet Control System Protocol) data and NetLinx ICSNet control throughout the NetLinx Control System. NetLinx ICSNet Hub Cards, ICSHub Server Cards and ICSHub Expander Cards can extend control up to 1,000 feet.
NETLINX HUB CARDS AND MODULES NXS-MHS Master/Hub Module Shell FG2009 Accepts NetLinx Processor ICSNet and ICSHub Cards. Includes faceplates for Master and Hub. NETLINX SYSTEM ACCESSORIES EXA Ethernet Crossover Adapter FG959-10 Used to allow direct connection (without a network hub) between a PC's 10/100baseT Ethernet port to a Landmark (PLC) or NetLinx (NXC) Master Card DIMENSIONS (HWD): • 1.50"x 5.55"x 8.75" (3.81 cm x 14.10 cm x 22.
NETLINX CUSTOM PANEL INTERFACE NETLINX 2-WAY WIRELESS SYSTEM PACKAGE *LIMITED AVAILABILITY* NI-CPNW NetLinx Wireless System Package FG840-K16 NXP-CPI16 NetLinx Custom Panel Interface FG410 The NXP-CPI16 NetLinx Custom Panel Interface is a versatile device, useful for both custom panel and contact-closure applications. It will directly interface with AMX Touch Panels and components designed for integration with Axcess Control Systems.
VIEWPOINT 1-WAY WIRELESS SYSTEM PACKAGE VPX-CPNI *LIMITED AVAILABILITY* NetLinx 1-way Wireless Touch Panel System FG841-K1-315 This control solution package Includes: • • • • • • • VPT-CP 315 MHz ViewPoint Color Wireless Touch Panel NI-2000 Integrated Controller Four CC-IRC infrared emitter cables One CC-COM programming cable One ViewPoint programming adapter cable AXR-RF RF 315 MHz Receiver PSN 2.8 12VDC, 2.
NETLINX PERIPHERALS / SOFTWARE NetLinx Peripherals / Software
NEXLINX SOFTWARE NETLINX PLATINUM SERIES SOLUTIONS AMX has created a series of prepackaged control solutions for multiple environments. We provide you the tools you need to facilitate the sale, ordering, delivery, installation and programming of your installation. By addressing specific vertical markets and applications, AMX has successfully developed hardware and software packages that do not require any additional configuration or programming time.
NEXLINX SOFTWARE NETLINX PLATINUM SERIES SOLUTIONS NSK-PPRES Presentation Solution System, Premium Edition FG3001-21 In today's media-driven presentation rooms – equipped with stereo equipment and computers – AMX provides this of one-touch integration solution perfect for controlling larger rooms.
NEXLINX SOFTWARE NETLINX INTERNET INSIDE SOLUTIONS Our exclusive Internet Inside Solutions are a series of software packages designed to enhance the NetLinx Control System's capabilities through the AMX Touch Panel. These innovative software applications combine the dynamics of NetLinx with the features of the World Wide Web. They are written directly into the control system programming language and are activated using AMX Touch Panel buttons. Take control of anything, from anywhere, at any time.
NETLINX INTERNET INSIDE SOLUTIONS i!-PCLink/Web Launch the Internet from the AMX Touch Panel FG070-509 Break free from the PC. Launch the Internet through the AMX Touch Panel – from anywhere, at any time. Visit different web sites and open a variety of computer files at the touch of a button. i!-Schedule Manage control system events based on date and time FG070-515 Take control of everything around you, with minimal effort. Save time. Save money.
CONTROL SYSTEM ACCESSORIES Control System Accessories
INPUT SENSORS VSS2 Video Sync Sensor FG5916-10 PCS Power Current Sensor (for US 110 VAC 3-pole receptacles) FG426 The PCS Power Current Sensor can sense high, low or no power level states for one device. It requires external DC power. FEATURES • Two open collector transistor outputs (On and Standby) • • • • LED indicators for Standby and On status Sensing for 30 mA-15 A power current levels 3-prong, grounded 120 VAC receptacle ENCLOSURE: Plastic with black matte finish DIMENSIONS (HWD): 3.1" x 2.
EQUIPMENT PROTECTION NXA-UPS9510 FG678 NXA-MPS16F FG677 A 19" Rack Mount surge protected UPS designed for AMX NetLinx systems. The UPS has a capacity of 1000/650 VA/W with a battery maintaining a recharge time of 5 hours (to 90% capacity). The unit comes with 8 NEMA 5-15R. FEATURES • • • • • • • • • • • The NXA-UPS9510 has multiple voltage selections using line interactive technology.
CONTACT CLOSURE INTERFACES PC2 AV2SM Dual Power Controller, 5 A (110 VAC only) FG675 Auto/Manual Video Switcher FG5919 This 2x1 video/stereo audio switcher can be set for automatic or manual operation. In the standard manual mode, a single latched closure is used to select and activate the “B" video input. In the automatic mode, the “B" input is programmed to switch instantly to the “A" input when “video sync" is detected. The “A" input, recognized as the default input, always has priority.
SYSTEM TOOLS IRIS EXA IR/Serial Data Capture Device FG5448 Ethernet Crossover Adapter FG959-10 Used to allow direct connection (without a network hub) between a PC's 10baseT Ethernet port to a Landmark or NetLinx Master Card. IRIS is a stand-alone, self-contained unit used to capture IR or wired function signals from a hand controller. Once captured and verified, the control functions are sent to a PC operating the IRLIB program.
POWER SUPPLIES PS-24VAC PSN6.5 12 VDC, 6.5 A Power Supply (regulated, 110 VAC input) FG423-41 24 Volt AC Power Supply FG424 The PS-24VAC power supply provides 40 VA of 24 volt AC power to the ViewStat Thermostats.
AMX STANDARD 10 FT.
VIEWSTAT COMMUNICATING THERMOSTAT SYSTEM The ViewStat Communicating Thermostat offers complete digital thermostat functionality, including the ability to schedule automatic temperature adjustments throughout the day, control relative humidity levels and poweroutage protection. ViewStat is available with (VST) and without (VST-TSTAT) an ICSNet MiniVerter interface, providing dealers with flexibility in deciding the control system interface.
INTEGRATED CONTENT SERVERS Integrated Content Servers
MAX INTEGRATED MUSIC SERVER (MAX-IMS) Welcome to a new and exciting world of music, where digital content can be stored, accessed, and displayed in the exact same quality as the original recordings. Build and control a library of CDs (and MP3s) with ease, and instantly play the stored content simultaneously, to different integrated environments. Introducing MAX, the Integrated Content Server from AMX that makes this all possible.
MAX INTEGRATED MUSIC SERVER (MAX-BMS) Welcome to a new and exciting world of music, where digital content can be stored, accessed, and displayed in the exact same quality as the original recordings. Build and control a library of CDs (and MP3s) with ease, and instantly play the stored content simultaneously, to different integrated environments. Introducing MAX, the Integrated Content Server from AMX that makes this all possible. MAX-BSM Backup Storage Module Think smart, plan ahead.
MAX MULTIMEDIA SERVER (MAX-MMS) Welcome to a new and exciting world of music and movies, where digital content can be stored, accessed, and displayed in the exact same quality as the original recordings. Build and control a library of CDs and DVDs with ease, and instantly play the stored discs simultaneously, from different integrated environments. Introducing MAX, the Integrated Multimedia Content Server from AMX that makes this all possible.
MAX MULTIMEDIA SERVER (MAX-MMS) Welcome to a new and exciting world of music and movies, where digital content can be stored, accessed, and displayed in the exact same quality as the original recordings. Build and control a library of CDs and DVDs with ease, and instantly play the stored discs simultaneously, from different integrated environments. Introducing MAX, the Integrated Multimedia Content Server from AMX that makes this all possible.
LIGHTING Lighting
AMX INCONCERT WITH LUTRON ALD-D48 AMX Network Lighting Solution Dimmer Interface FG2604 The ALD-D48 is the heart of an AMX integrated network lighting solution. The programmatic interface to the ALD-D48 appears similar to an AMX native device in that it utilizes a standard AMX command set. When used with ALD dimmers and switches a complete NetLinx compatible lighting system is formed. Each ALD-D48 can support up to 48 Vareo switches (12 buses with four switches per bus).
RADIA LIGHTING CONTROL ENCLOSURES RDA-ENC2 RDA-ENC8W Radia Lighting 2 Space Enclosure FG606-10 8-Module In-Wall Enclosure FG606-17 FEATURES In-wall enclosure mounts between 16.00" centered studs, provides eight spaces for Radia Control Cards, Modules and Integrated Dimming Modules. • • • Supports installation of single-phase Dimmer Cards Provides two spaces for Radia Lighting Cards and Modules Six knockouts for 1/2", 3/4", and 1" conduit DIMENSIONS (HWD): 12.00" x 6.00" x 6.
RADIA CONTROL CARDS INTEGRATED DIMMER MODULES INTEGRATED DIMMER MODULE FEATURES RADIA CONTROL CARD FEATURES • • • • • • • Delivers digital dimming control to Radia Modules from six control ports, as well as onboard system processing, networking, and non-volatile preset memory Drives all channels using the same power phase Stores 128 onboard presets, each can use unique fade time Ramps using programmable fade time, from 0 to 255 seconds Provides up to 16 different dimming curves for precision control Adap
RADIA DIMMER MODULES RDM-DC RDM-INC Incandescent Dimmer Module, 2,400 W FG606-30 DC Module, 1,920 W, 0-12 VDC FG606-60 Application • • • • APPLICATION • • • • • • • 20A Incandescent-compatible dimming General-purpose switching, no positive air gap 40A SCR, 350 microsecond rise time choke Installs in one enclosure space UL/CUL listed for continuous-duty operation Suitable for 120/240/277 VAC applications • • Dims one circuit DC-controlled electronic fluorescent ballasts Ramps 0–12 VDC signal for level
RADIA DIMMER MODULES *LIMITED AVAILABILITY* RDM-HDC RDM-2SWM Heavy-Duty DC Module, 2,400 W, 0-12 VDC FG606-63 Dual Switch Module, 20A FG606-51 APPLICATION • • APPLICATION • • • • • • • • Dims DC-controlled electronic fluorescent ballasts Ramps 0–12 VDC signal for level control 20A Positive air gap relay for power Current sourcing or current sinking Installs in one enclosure space UL/CUL listed for continuous-duty operation Suitable for 120/240/277 VAC applications • • Two 20A positive air-gap relay
RADIA SWITCH MODULES RDM-HSW *LIMITED AVAILABILITY* RDM-ZC Heavy-Duty Switch Module, 20A FG606-53 Zero Cross Module, 20A FG606-40 APPLICATION APPLICATION • • • • • 20A heavy-duty positive air-gap relay Heavy-duty switching applications Installs in one enclosure space UL/CUL listed for continuous-duty operation Suitable for 120/240/277 VAC applications • • • • • • RDM-2HSW 20A module switches fixtures at the zero-cross point of AC waveform 40A solid-state SCR Recommended for electronic fluorescent
PRO DIMMER KITS RADIA PROLINK FLUSH MOUNT KEYPADS RDK-ENC12B PRO-DP8 Radia 12-Channel Pro Dimmer Kit, 120 or 240 VAC FG606-95K Includes RDA-ENC12B/120 enclosure and two RDC-PDC/120 cards FG606-96K Includes RDA-ENC12B/240 enclosure and two RDC-PDC/240 cards Decor PROlink Flush Mount Keypad Panel (single gang) FG5790-10 White FG5790-11 Black FG5790-12 Ivory APPLICATION • • • • • Supports multi-phase wiring for both RDA-PDC Dimmer Cards Includes 12 20A circuit breakers 120/208 VAC, 4W+G Provides six spa
CAMERA CONTROLLERS Camera Controllers
SYSTEM ACCESSORIES CAMERA CONTROLLERS AXP-CCS Softwire Camera Center FG630-31 AXP-PLV PosiTrack Pilot Video Touch Panel FG5630-80 Designed with the camera operator in mind, the PosiTrack Pilot Video Touch Panel includes a 6" color-active Touch Panel with a video display, a proportional pan/tilt/zoom joystick and focus, iris and speed controls. With the right hand on the soft wrist pad, the operator can intuitively guide the camera, and twist the joystick, to zoom the lens in and out.
CAMERA CONTROLLERS AXM-CCS Rack-Mount Softwire Camera Center FG630-35 The AXP-CCS Rack-Mount Softwire Camera Center combines precision proportional joystick pan/tilt and lens control with interactive softwire pushbutton control. Illuminated buttons select up to six cameras with as many as 24 preset shots per camera. Optional software allows for 18 cameras, eight preset control. Buttons are also provided for iris open, close and automatic/manual operation.
POSITRACK PAN/TILT HEADS The PosiTrack Pan/Tilt Heads are fully integrated camera positioning controllers. All three models are capable of commanding a camera's pan and tilt functionality, as well as lens zoom, focus and iris features. The PosiTrack Heads provide seamless broadcast-quality control at an appealing economical price. The PosiTrack Heads are designed with a smooth, quiet-motion analog motor drive that incorporates precision digital position sensing.
AXCESS CONTROLLERS Axcess Controllers
AXCESS VPX-CP VIEWPOINT XPRESS 2-WAY WIRELESS SYSTEMS *LIMITED AVAILABILITY* ViewPoint Xpress Color System FG840-K3 418 MHz (1-way IR/RF) FG840-K3-304 304 MHz (1-way IR/RF) FG840-K3-433 433 MHz (1-way IR/RF) *LIMITED AVAILABILITY* FG840-K3-310 310 MHz (1-way IR/RF) FG840-K3-315 315 MHz (1-way IR/RF) VPX-CPNW ViewPoint Xpress Color System FG840-K9 NetWave 2-way 2.
AXCENT 3 & AXCENT3 PRO AXCESS CARDFRAMES AXCENT 3 PRO CONTROL PORTS • • • Integrated Axcess ControlFrame FG5955-30 Six IR/Serial/RS-232 ports (1-way RS-232 300-38,400 baud, 0-5 VDC) Six RS-232/422/485 ports, 9-pin male D-sub connectors (2-way 300-115,200 baud), XON/XOFF, CTS/RTS Eight relays (normally open) rated at 750 mA, 28 VAC/24 VDC Six input/output channels, rated at 200 mA, contact closure or TTL logic inputs POWER • 600 mA @ 12 VDC (minimum; not including control cards or bus devices) INCLUDE
AXCESS CARDFRAMES AXB-SPE AXF-MINI Mini-CardFrame (up to 3 AXC control cards) FG731 Holding up to three Axcess control cards, the Axcess Mini-CardFrame fits between full CardFrames and Bus Controllers. For example, a system may need a unique combination of control cards located close to a remote camera pan/tilt/lens head. In another, the Mini-CardFrame could add three volume cards to an AXCENT2 system. A distributed system may use the unit for IR, relay and volume control in small meeting rooms.
AXCESS PROCESSOR CARDS AXC-232++ RS-232/422/485 Interface Card (enhanced functionality) FG725-10 AXC-EM Enhanced System Master Card FG711 Fully compatible with Axcess software, the AXC-EM manages system operation and executes control system programs. This Enhanced Master Card can coordinate the activities of up to 255 different pieces of equipment, such as other control cards, bus controllers and various input devices.
AXCESS CONTACT CLOSURE CARDS AXCESS DATA CONTROL CARDS AXC-IR/S AXC-INP8 IR/Serial Card FG740 8 Input Card FG785 Most audiovisual devices, such as audio and video cassette recorders, compact disc players and tuners, can be remotely controlled by either infrared (IR) or serial data commands. The AXC-IR/S Infrared Serial Card generates programmed commands specific to each device by manufacturer, model number and function. Up to 128 functions can be programmed into each card.
AXCESS CONTACT CLOSURE CARDS AUDIO CONTROL CARDS AXC-VOL AXC-REL8 2-Channel Volume Control Card FG755 8 Relay Card FG715 Devices that require a simple momentary or latching contact closure can be controlled with the AXC-REL8 Universal Eight Relay Card. This card can operate up to 8 relay-controlled functions, and cards can be linked together to allow a larger number of functions. Adjacent relays on the card may be selectively commoned to reduce device wiring.
VOLTAGE RAMP CARDS AXC-PTI AXC-VG24 Pan/Tilt Interface Card (requires high power DC supply) FG768 Voltage Ramp Generator Card (24 VDC) FG736 Closed circuit television (CCTV) and teleconferencing applications often require that the audiovisual control system monitor display each camera’s position, as well as move them to cover participants or scenes.
SPECIAL APPLICATION CARDS AXC-EXTN Extender Card FG760 APPLICATION • • Extends any Axcess Control Card for service or testing Allows installer to troubleshoot operation while card is installed AXC-TEMP Temperature Control Card FG749-K The AXC-TEMP Temperature Control Card provides control and power for the RTS1 Room Temperature Sensor. The RTS1 provides precision temperature sensing for the AXT-TEMP.
DATA CONTROLLERS AXB-232++ RS-232/422 Interface (enhanced functionality) FG5761-10 AXB-DTMF+ DTMF Interface FG946 While this controller can serve as a conventional RS-232/422 control port, it is also able to run its own Axcess application program – an exclusive AMX product feature. Source specific programming, such as video switchers, laserdisc players and video codecs, can be handled by the AXB-232++ to deliver a modular solution for system programming.
DATA CONTROLLERS AXB-TC AXB-MIDI Television Controller FG5928 MIDI Interface FG5913 The versatile AXB-MIDI can receive data from two independent MIDI IN (A, B) ports to provide automated control of audio mixers, routers and other MIDIcompatible devices. MIDI “IN A" and “IN B" are combined with “THRU" and “OUT," which can be re-patched under software control. System-generated MIDI commands are sent to “OUT.
DATA CONTROLLERS AXB-TM5 Television Manager (38/455 kHz IR) FG5690 The AXB-TM5 is an intelligent, microprocessor-controlled, video routing and control system. Mounted near a television monitor or video projector, the Television Manager provides media source selection and control management via remote control. It acts as a local Axcess controller and receiver for a wireless AMX Touch Panel. FEATURES • • • • • • Receives Pioneer IR barcode wand (models LDV-2200 and CLD-2400) commands.
DATA CONTROLLERS AUDIO CONTROLLERS AXB-VOL3 3-Channel Volume Controller FG5756 AXB-TMX+ Television Manager FG689 The AXB-TMX+ provides the same features as the AXB-TMC, but without the clock display. The built-in RS-232 port of the AXB-TMX+ can take control of local switchers, projectors and other electronic sources. It can also be used for direct, external RS-232 control in non-AXLink applications.
CONTACT CLOSURES CONTROLLERS AXB-REL8 AXB-SLD Relay Controller FG5774 Slide Controller FG5777-10 The AXB-REL8 controls closure-activated devices, acting as an eight-channel relay control port on the AXLink bus. CONTROL PORTS • Eight relays, normally open, rated at 750 mA, 28 VAC/24 VDC INCLUDES • • Front-panel device addressing switches and status LEDs Metal tab strips for communing adjacent relays ENCLOSURE: Metal with black matte finish DIMENSIONS (HWD): 1.5" x 5.5" x 5.
LANDMARK CONTROLLERS Landmark Controllers
LANDMARK LANDMARK CARDFRAMES PLB-CF10 LANDMARK MASTER CARDS PLC-MCU4 4MB Master Control Card FG754 Cardframe with 10 Card Slots and 16 Port Hub FG993 APPLICATION FEATURES PHASTLAN • • • • Holds up to 10 control cards Acts as system master with Master Control Card Operates interactively over high-speed Ethernet connection to system PC with PHAST software and PLC-MCU Card Distributes PHASTLink from 15-port PHASTLink data hub • • Master system processing and memory one required per system RJ-45 Ether
LANDMARK CONTROL CARDS LANDMARK HUB AND AV MATRIX CARDS PLC-IROUT PLH-MIC IR Output Card FG0734 Microphone Hub Card, 8 PHASTLink and MIC Ports FG936 APPLICATION FEATURES • Control of IR-format sources • PORTS 1-4 • 4 outputs, IR or wired IR up 10 MHz • WIRING • 4 mini-phono jacks for emitter or wired IR cable • POWER • • HUB IN AND OUT 75 mA • PLC-RL8 8-Relay Card FG0722 • APPLICATION • • RJ-45 Hub In port One RJ-45 Hub Out port PHASTLINK 1-8 Eight RJ-45 PHASTLink ports MIC 1-8
LANDMARK HUB AND AV MATRIX CARDS PLB-AS8 8x8 Stereo Audio Switch FG991-10 PLB-AMP8 8-Channel Audio Amplifier FG990 FEATURES • • • • • Routes eight stereo line-level audio inputs to eight stereo line-level outputs Distributes any input to any combination of outputs Full pre-amp control for volume, balance, mute, loudness, bass, and treble for each channel Senses presence of signal at each input to act as a trigger for system events Provides interactive control and feedback with PHAST system INPUTS • 16
LANDMARK KEYPADS PLK-DMS PLK-SB Direct Menu Select Keypad FG2405-01 White FG2405-02 Black FG2405-03 Ivory FG2405-04 Almond 1-and 2-Button Flush Mount Keypads FG2406-10 White Decora style FG2406-11 Black Decora style FG2406-12 Ivory Decora style Displays multiple pages of menus under program control offering new control options, lists of CD titles, time, date, temperature and other applications.
LANDMARK KEYPADS PLK-MSP32 PLK-MSP8 Decor 32-Button Mini-Softwire Panel (3 bargraphs, 3 gang) PFG790-32 White Decora style (3 bargraph, 3 gang) PFG790-33 Black Decora style (3 bargraph, 3 gang) PFG790-34 Ivory Decora style (3 bargraph, 3 gang) Decor 8-Button Mini-Softwire Panel PFG790-08 White Decora style (1 bargraph, 1 gang) PFG790-09 Black Decora style (1 bargraph, 1 gang) PFG790-10 Ivory Decora style (1 bargraph, 1 gang) FEATURES • • • Provides up to eight control buttons with LED feedback and one
LANDMARK ACCESSORIES SAM MODULES PLH-BLANK PMBSAM Hub Card Blank Plate FG996 PFG636-09 EXTRON Switcher Serial Access Module PFG636-13 AUTOPATCH Serial Access Module PFG636-14 B&W (CASA) Serial Access Module PM-RAC PFG636-15 ROTEL (B&W) Serial Access Module Large Chassis Rack Mount Kit FG529 PFG636-16 RGB SPECTRUM Serial Access Module PFG636-20 MADRIGAL Internally installed PM-RAC2 PFG636-21 LEXICON Serial Access Module PLB-CF2 Rack Mount Kit FG500 PFG636-22 YAMAHA Serial Access Modul
SAM MODULES PFG636-64 FOCUS ENHANCEMENTS Serial Access Module Kits PFG636-65 ARRAKIS DC6 Serial Access Module PFG637-57 PFG636-66 LINN KIVOR Serial Access Module Landmark Carrier Comfort (Includes AXB-EM232, PMBSAM) PFG636-67 EUROPLEX ADPLEX Serial Access Module PFG637-58 PFG636-68 MBOX Serial Access Module Landmark Carrier VVT3 I (Includes AXB-EM232, PMBSAM) PFG636-69 ESCIENT FIREBALL/TUNEBASE 200 Serial Access Module PFG636-70 MEDIA ACCESS SOLUTIONS Serial Access Module (MAX-MMS, MAX-IMS
MX CONTROLLERS MX Controllers
MX SINGLE PROJECTOR CONTROLLERS MX4 Fwd, Rev, Focus In/Out FG257-10 MX2 Fwd, Rev FG252-10 INCLUDES • Includes • • • • MX2TX Transmitter - Dimensions (HWD): 5.4" x 1.8" x 1.5" (137 mm x 46 mm x 38 mm) - Weight: 3.2 oz (91 g) MX2 Wireless Receiver - Frequency: 304 MHz standard - Power: Powered by US Kodak style slide projector - Dimensions (HWD): 1.5" x 5.1" x 5.1" (38 mm x 129 mm x 129 mm) - Weight: 11.
MX MOBILE WIRELESS MOUSE MX-MM Mobile Mouse (PC only) FG5650 TRANSMITTERS ONLY MX12TX 12 Buttons, 12 Functions FG290-04 MX ACCESSORIES MX-PS Power Supply FG423-60 13.
TRAINING Training
AMX UNIVERSITY LEARNING OPPORTUNITIES To effectively meet your business needs and accommodate your schedule, AMX University offers a variety of learning opportunities that will enhance your knowledge of AMX products. • Classroom Learning – Experience an interactive hands-on environment facilitated on-site by world-class AMX instructors. • Live Online Learning – Take advantage of the benefits of classroom instruction from the convenience of your desk.
AMX UNIVERSITY AMX Designer • On Demand Online Learning for Designers, Sales Professionals and Consultants. • After completing this two-hour Web-based course, you will be able to design and document a basic AMX Control System. Using the provided AMX tools you will be able to identify and practice the four steps involved in designing a Control System. You will get to practice the steps with two independent scenarios that will also prepare you for the certification exam.
PROFESSIONAL SERVICES Professional Services
PROFESSIONAL SERVICES GROUP Audiovisual and energy management control systems are more complex than ever. The integration of traditional systems with network-based capabilities and subsystems are increasingly sophisticated. No matter the application, commercial or residential, achieving success for your business requires a highly skilled staff or a trusted partner to assist your needs. There is no better solution than AMX Professional Services Group (PSG). We do this for a living.
