Setup Pages
60
MVP-8400i Modero Viewpoint Wireless Touch Panels
Environmental acoustics, personal voice level and ambient noise are all deciding factors when setting
your mic, intercom and panel sound levels. Consider your environment when adjusting intercom and
sound levels and use caution so as not to damage the speaker.
WAV files - Supported sample rates
The following sample rates for WAV files are supported by MVP-8400 panels:
Volume Page (Cont.)
Default Panel Sounds: • Activating the Button Hit button plays a default sound when you touch an
active button.
• Activating the Button Miss button plays a default sound when you touch a
non-active button or any area outside of the active button
• The Play Test Sound button plays a test WAV/MP3 file over the panel’s
internal speakers.
Internal Sound Level: Adjusts the volume level on the panel’s internal speaker:
• Use the UP/DN buttons to adjust the volume (range = 0 - 100)
• The Internal Sound Level bargraph indicates the current sound level
• The Mute button mutes the internal speaker volume
Default = 50
Intercom Mic Level: Adjusts the volume level on the panel’s microphone
• Use the UP/DN buttons to adjust the microphone level (range = 0 - 100)
• The Mic Out Level bargraph indicates the current Mic Out level
Default = 40
Intercom Sound Level: Sets the volume level for intercom calls
• Use the UP/DN buttons to adjust the Line-In volume level (range = 0 - 100)
• The Line-In Level bargraph indicates the current Line-In level
• The Mute button mutes the Line-In volume
Default = 40
Supported WAV Sample Rates
• 48000 Hz • 16000 Hz
• 44100 Hz • 12000 Hz
• 32000 Hz • 11025 Hz
• 24000 Hz • 8000 Hz
• 22050 Hz
