Wireless Interface Cards
13
MVP-7500/8400 Modero Viewpoint Wireless Touch Panels
Supports authentication methods such as: EAP-FAST, EAP-LEAP, EAP-PEAP, EAP-TLS,
and EAP-TTLS
Supports Wired Equivalent Privacy (WEP) 64-bit and 128-bit data encryption (known to the
on-board firmware as Static WEP)
The NXA-WC80211GCF is backwards compatible with 802.11b networks.
This upgrade kit requires that pre-existing panels first be removed from their current location (surface,
wall or docking station) before an installer can access the internal circuit boards and upgrade a pre-
existing 802.11b wireless CF card.
MVP panels require the use of a cardboard cutout (Mounting Template) to properly position the metal
antenna plate onto the inner surface of the unit’s rear plastic housing.
Specifications
To fully utilize wireless security features, this card must be used in tandem with the
latest Modero firmware upgrade available at www.amx.com.
NXA-WC80211GCF Specifications
Dimensions (HWD): • 0.22" x 1.68" x 2.40" (5.6 mm x 42.80 mm x 61.0 mm)
Weight: • 19.50 grams (0.043 lbs)
Description: • Wireless LAN Compact Flash Card with external PIFA antenna.
• Features enterprise-class security such as WPA and WPA2 security.
•
Antenna Type: • External PIFA antenna (factory-installed)
Bus Interface: • Compact Flash Type I
Certifications: • FCC Part 15 Class B, CE, IC, TELEC, and Wi-Fi
Media Access Control
Techniques:
• Using 802.11b DSSS communication:
DBPSK @ 1 Mbps
DQPSK @ 2 Mbps
CCK @ 5.5 Mbps
• Using 802.11g OFDM communication:
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-QAM @ 24 and 36 Mbps
64-QAM @ 48 and 54 Mbps
Network Architecture: • Infrastructure mode (Client-to-Access Point)
Operating Channels: • Using 802.11b & g communication:
- 04: (Ch 10 - 13) - France
- 11: (Ch 1 - 11) - North America
- 13: (Ch 1 - 13) - Europe ETSI
- 13: (Ch 1 - 13) - Japan (802.11g)
- 14: (Ch 1 - 14) - Japan (802.11b)
Note: To alter the card’s default country code (North America), contact an AMX
Technical Support representative for detailed procedures and information.
NXA-WC80211GCF Specifications (Cont.)
