Programming
132
MVP-8400i Modero Viewpoint Wireless Touch Panels
Text Effects Names
The following is a listing of text effects names (associated with the ^TEF command on page 130).
MVP Panel Lock Passcode Commands (Cont.)
^LPR
Remove a given
user from the User
Access
Passwords list on
the Password
Setup page.
Syntax:
"'^LPR-<user>'"
Variable:
user = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^LPR-Robert'"
Remove user named ’Robert’ from the User Access Password list on the Password
Setup page. Refer to the
Password Setup Page section on page 104 for more
information.
^LPS
Set the user name
and password.
This command allows you to:
1. Add a new user name and password OR
2. Set the password for a given user.
The user name and password combo is added to the User Access and/or Password list
in the Password Setup page. The user name must be alphanumeric.
Syntax:
"'^LPS-<user>,<passcode>'"
Variable:
user = 1 - 50 ASCII characters.
passcode = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^LPS-Manager,undock'"
Sets a new user name as "Manager" and the password to "undock".
Example 2:
SEND_COMMAND Panel,"'^LPS-Manager,test'"
Changes the given user name password to "test".
Refer to thePassword Setup Page section on page 104 for more information.
Text Effects
•Glow -S • Medium Drop Shadow 1 • Hard Drop Shadow 1
•Glow -M • Medium Drop Shadow 2 • Hard Drop Shadow 2
•Glow -L • Medium Drop Shadow 3 • Hard Drop Shadow 3
•Glow -X • Medium Drop Shadow 4 • Hard Drop Shadow 4
• Outline -S • Medium Drop Shadow 5 • Hard Drop Shadow 5
• Outline -M • Medium Drop Shadow 6 • Hard Drop Shadow 6
• Outline -L • Medium Drop Shadow 7 • Hard Drop Shadow 7
• Outline -X • Medium Drop Shadow 8 • Hard Drop Shadow 8
• Soft Drop Shadow 1 • Medium Drop Shadow 1 with outline • Hard Drop Shadow 1 with outline
• Soft Drop Shadow 2 • Medium Drop Shadow 2 with outline • Hard Drop Shadow 2 with outline
• Soft Drop Shadow 3 • Medium Drop Shadow 3 with outline • Hard Drop Shadow 3 with outline
• Soft Drop Shadow 4 • Medium Drop Shadow 4 with outline • Hard Drop Shadow 4 with outline
• Soft Drop Shadow 5 • Medium Drop Shadow 5 with outline • Hard Drop Shadow 5 with outline
• Soft Drop Shadow 6 • Medium Drop Shadow 6 with outline • Hard Drop Shadow 6 with outline
• Soft Drop Shadow 7 • Medium Drop Shadow 7 with outline • Hard Drop Shadow 7 with outline
• Soft Drop Shadow 8 • Medium Drop Shadow 8 with outline • Hard Drop Shadow 8 with outline
