Running i!-PCLink/PowerPoint
16
i!-PCLinkPowerPoint
i!-PCLink/PowerPoint Module (Cont.)
nchFilesCtrl
An INTEGER array for file list control supporting the following buttons (in this
order): Page Up, Page Down, Top of List, Bottom of List.
nchShortcuts
An INTEGER array for shortcuts supporting the following buttons (in this
order): Select, Edit, Shortcuts 1-10.
nchSysInfo
An INTEGER array for status information supporting the following buttons (in
this order): PowerPoint device is online, Busy Loading Presentation.
nvtPresentation
An INTEGER array for presentation information supporting the following
variable text channels (in this order): Slide Show Progress Text, Slide Show
Progress Level, Current Slide Title, Presentation Name.
nvtTimes
An INTEGER array for show/slide time supporting the following variable text
channels (in this order): Show Time, Slide Time.
nvtNotes
An INTEGER array for speaker notes supporting the following variable text
channels (in this order): Speakers notes 1 - 5.
nvtSlides
An INTEGER array for slide browsing list supporting the following variable text
channels (in this order): Slide Titles 1 - 7.
nvtFiles
An INTEGER array for file browsing list supporting the following variable text
channels (in this order): File names 1 - 7.
nvtIcons
An INTEGER array for file icon list supporting the following variable text
channels (in this order): File icons 1 - 7.
nvtShortcuts
An INTEGER array for shortcuts supporting the following variable text channels
(in this order): Shortcut names 1 - 10.
nvtSysInfo
An INTEGER array for file icon list supporting the following variable text
channels (in this order): NetLinx IP address, PowerPoint device number,
NetLinx system number.
nIconDrive
The icon number from your touch panel file for the Drive icon for the file list.
nIconDir
The icon number from your touch panel file for the Directory icon for the file list.
nIconPpt
The icon number from your touch panel file for the PowerPoint file icon for the
file list.
NO_BUTTON
The channel number interpreted as "NO BUTTON" , i.e. feedback is not
executed for this channel. Any channel appearing in an nchXXX parameter
with this value will not receive any feedback commands from the module.
