User Guide
Table Of Contents
- DXP v1.5 - Programmer's Guide
- Introduction
- Using the Design XPress Project Wizard
- Overview
- Launching the Design XPress Project Wizard
- Using the Design XPress Project Wizard
- User Information dialog
- System Information dialog
- System Configuration dialog
- Which Screens? dialog
- Audio Zones dialog
- Audio Sources dialog
- Video Inputs dialog
- HVAC Zones dialog
- DMS Keypads dialog
- SB2 Keypads dialog
- Door Phones dialog
- Touch Panel Declarations dialog
- Choose Background Images dialog
- Choose Button Colors dialog
- Choose Button Text Colors dialog
- Choose Bargraph Color dialog
- Touch Panel Control dialogs
- House Lighting Scenes dialog
- Control Button Labels dialog
- CD Titles dialog
- DSS TV Favorites dialog
- DSS Music Favorites dialog
- Tuner Presets dialog
- Finishing a Project
- Understanding the Report File
- Transferring Preset Button Text to the Master via FTP
- Opening an Existing Design XPress Project
- Copying a Design XPress Project
- Importing a Design XPress Project
- Exporting a Design XPress Project
- Deleting a Design XPress Project
- Using NetLinx Studio
Introduction
3
D
esign XPress Programmer’s Guide
1-16 Touchpanels
0-32 HVAC Zones (ViewStat ICSNet, ViewStat RS-422 or OPStat)
0-32 SB2 Keypads
0-4 Door Phones (Techlon Instruments, Inc. or Generic I/O based)
0-24 Video Inputs
Supported Subsystems and Equipment
Design XPress (v1.5) supports the following subsystems and equipment:
AMX NetLinx Integrated Controllers
NI-2000
NI-3000
NI-4000
NXC-ME260/64
AMX Touch Panels
G4 Firmware Panels:
MVP-7500: Wireless Panel
MVP-8400: Wireless Video Panel
NXT/NXD-CV7: 7" Touch Panel with video
NXT/NXD-CA12: 12" Touch Panel
NXT/NXD-CV12: 12" Touch Panel with video
NXT/NXD-CA15: 15" Touch Panel
NXT/NXD-CV15: 15" Touch Panel with video
NXT/NXD-CV17: 17" Touch Panel with video
G3 Firmware Panels:
AXT/AXD-CP4/A: 4" Touch Panel
AXD-CV6: 6" Video Touch Panel
AXT/AXD-CA10: 10" Touch Panel
AXT/AXD-CG10: 10" Touch Panel
AXT/AXD-CV10: 10" Video Touch Panel
The nomenclature " NXT" indicates the table-top (tilt) model, and "NXD" represents
the wall-mount version.
