Creating Touch Panel Declarations
Design Xpress supports up to 16 touch panels in a System. To create the touch panel declarations
for your system:
1. Select a Panel in the Touch Panel Interfaces list. The number in this column represents the
number of panels specified in the System Configuration dialog (see the System Configuration
dialog section on page 20 for details).
2. Enter a descriptive name for the panel in the Display Name text field.
Adding a New Touch Panel Interface:
1. Increase the number of Touch Panels in the system in the Touch Panels field of the System
Information dialog by one (to allow an additional Touch Panel to be defined in the Touch Panel
Declarations dialog).
2. Enter a name for the new panel in the Display Name field.
3. Select a panel type from the Panel Type drop-down list.
4. Click the Apply button to add the newly configured panel.
Touch Panel Declarations dialog
• Touch Panel Interfaces This table lists all of the touch panels currently defined in your Project (via the Touch
Panels entry in the System Information dialog. This table displays several types of
information for each panel, separated into five columns:
• Panel ID: The Panel ID is based on the number of panels specified in the System
Information dialog. This field cannot be edited in this dialog. To remove panels, or
from the Project, go to the System Information dialog.
• Display Name: The Display Name indicated here is based on the order in which
the panels were added to the project (Panel1, Panel2, etc).. You can change the
default display name by editing the Display Name text field at the bottom of this
dialog, and click the Apply button.
• Ty pe : This column displays the model number and description of each touch panel
in the list. You can change the panel type via the Panel Type drop-down list at the
bottom of this dialog (click the Apply button to save the change).
• Audio Zone: This column indicates the audio zone that each panel is associated
with. To change the audio zone for a panel, click the down arrow next to the Audio
Zone field at the bottom of this dialog and select the desired audio zone from the
drop-down list of audio zones defined in your Project, and click the Apply button.
• Video: This column displays the output of the Video Switcher (1-24) that could be
controlled by the touch panel (if the panel video-capable).
• Use PictureFrame For
Inactivity Page:
Click this option to use the PictureFrame application as a screensaver when the
touch panel becomes inactive. If this option is selected, you'll have to open the TP4
file created by the DXP wizard, and configure the dynamic image properties to pull
images from the PC running the PictureFrame application.
Note: If the panel timeout is set to zero, the panel will never go to the Inactivity Page.
Panel Timeout is a setting that is made directly on the touch panel (via the Setup
pages on the panel).
• Apply Click to apply any changes made to a selected touch panel.
• Clear Click to deselect any selected touch panel and clear the editable fields at the bottom
of this dialog.
