2. Click the checkbox for Group 1 to add the specified Room/Location to Group 1. Now you
need to add at least one more Room / Location to Group 1.
3. Open the drop-down list of Room / Location Names for Zone 2 and select another Room /
Location to add to Group 1 (in the example above, the designer selected to group the Dining
room with the Kitchen).
4. If the Use Video checkbox was selected in the System Information dialog, the Video Output to
Zone drop-down menu is enabled. To associate a video output to a zone that provides video
output, select the desired Video Output (1-24) from the drop-down.
 If the Zone is included in a Group (or added to a Group), the first item in the Group listing
determines the Video Output value, and subsequent entries in that Group are disabled.
 In the example shown above, since Kitchen and Dining are in the same Group (Group 1),
and first entry in Group 1 (Kitchen) is set to use Video Output 1, then Dining will also use
Video Output 1. If there were other Rooms/Locations in Group 1, they would use Video
Output 1 as well.
5. Add as many additional Room / Locations to Group 1 as desired.
6. Once you are done configuring Group 1, repeat the process for Groups 2, 3 and 4 as needed.
The number of Zones that are enabled in this dialog is a reflection of the number of
Audio Zones (up to 30) specified in the System Information dialog.
You are allowed to set multiple (or all) zones to the same video output value.
Each incremental Group requires at least 2 selections. Changing selections that
cause less than 2 selections in any Group will result in subsequent Groups being
disabled.
