Function Codes (Cont.)
Page Name Button Name Channel Port:Code Address Port:Code Level Port:Code
Temperature (Cont.)
HVAC_OVERVIEW_COOL_POINT_ZONE6 3:27 3:27
HVAC_OVERVIEW_HEAT_POINT_ZONE6 3:28 3:28
HVAC_OVERVIEW_MODE_ZONE6 3:29 3:29
HVAC_OVERVIEW_FAN_ZONE6 3:30 3:30
HVAC_NAME_ZONE7 3:49
HVAC_OVERVIEW_TEMPERATURE_ZONE7 3:31 3:31
HVAC_OVERVIEW_COOL_POINT_ZONE7 3:32 3:32
HVAC_OVERVIEW_HEAT_POINT_ZONE7 3:33 3:33
HVAC_OVERVIEW_MODE_ZONE7 3:34 3:34
HVAC_OVERVIEW_FAN_ZONE7 3:35 3:35
HVAC_NAME_ZONE8 3:50
HVAC_OVERVIEW_TEMPERATURE_ZONE6 3:36 3:36
HVAC_OVERVIEW_COOL_POINT_ZONE8 3:37 3:37
HVAC_OVERVIEW_HEAT_POINT_ZONE8 3:38 3:38
HVAC_OVERVIEW_MODE_ZONE8 3:39 3:39
HVAC_OVERVIEW_FAN_ZONE8 3:40 3:40
HVAC_UI_ZONE1 3:201
HVAC_UI_ZONE2 3:202
HVAC_UI_ZONE3 3:203
HVAC_UI_ZONE4 3:204
HVAC_UI_ZONE5 3:205
HVAC_UI_ZONE6 3:206
HVAC_UI_ZONE7 3:207
HVAC_UI_ZONE8 3:208
TEMP_PREVIOUS_PAGE 3:41 3:41
TEMP_NEXT_PAGE 3:42 3:42
Video
VIDEO_SELECT_BUTTON 3:100 3:100
VIDEO_FULL_SCREEN_BUTTON 3:100 3:100
VIDEO_VIDEO_WINDOW 3:100 3:100
VIDEO_SETUP_BUTTON 0:97 0:81
CD1_TP_PLAY_BUTTON 1:21
CD1_TP_STOP_BUTTON 1:24
CD1_TP_PAUSE_BUTTON 1:27
CD1_TP_PREV_BUTTON 1:25
CD1_TP_NEXT_BUTTON 1:26
SAT1_TP_RIGHT_BUTTON 2:3
SAT1_TP_DOWN_BUTTON 2:4
SAT1_TP_LEFT_BUTTON 2:2
SAT1_TP_UP_BUTTON 2:1
SAT1_TP_SELECT_BUTTON 2:5
Lighting
LS1_TP_HOUSE_SCENE1_BUTTON 1:171
LS1_TP_HOUSE_SCENE2_BUTTON 1:172
LS1_TP_HOUSE_SCENE3_BUTTON 1:173
LS1_TP_HOUSE_SCENE4_BUTTON 1:174
