Design XPress Installer’s Guide
Function Codes (Cont.)
Page Name Button Name Channel Port:Code Address Port:Code Level Port:Code
Music (Cont.)
AUD_TP_ZONE26_BUTTON 1:76
AUD_TP_ZONE26_STATE 1:76 2:86
AUD_TP_ZONE27_BUTTON 1:77
AUD_TP_ZONE27_STATE 1:77 2:87
AUD_TP_ZONE28_BUTTON 1:78
AUD_TP_ZONE28_STATE 1:78 2:88
AUD_TP_ZONE29_BUTTON 1:79
AUD_TP_ZONE29_STATE 1:79 2:89
AUD_TP_ZONE30_BUTTON 1:80
AUD_TP_ZONE30_STATE 1:80 2:90
AUD_TP_GOTO_SOURCE_BUTTON 1:220
AUD_TP_MULTISEL_BUTTON 1:238
AUD_TP_SELALL_BUTTON 1:237
Temperature
HVAC_NAME_ZONE1 3:43
HVAC_OVERVIEW_TEMPERATURE_ZONE1 3:1 3:1
HVAC_OVERVIEW_COOL_POINT_ZONE1 3:2 3:2
HVAC_OVERVIEW_HEAT_POINT_ZONE1 3:3 3:3
HVAC_OVERVIEW_MODE_ZONE1 3:4 3:4
HVAC_OVERVIEW_FAN_ZONE1 3:5 3:5
HVAC_NAME_ZONE2 3:44
HVAC_OVERVIEW_TEMPERATURE_ZONE2 3:6 3:6
HVAC_OVERVIEW_COOL_POINT_ZONE2 3:7 3:7
HVAC_OVERVIEW_HEAT_POINT_ZONE2 3:8 3:8
HVAC_OVERVIEW_MODE_ZONE2 3:9 3:9
HVAC_OVERVIEW_FAN_ZONE2 3:10 3:10
HVAC_NAME_ZONE3 3:45
HVAC_OVERVIEW_TEMPERATURE_ZONE3 3:11 3:11
HVAC_OVERVIEW_COOL_POINT_ZONE3 3:12 3:12
HVAC_OVERVIEW_HEAT_POINT_ZONE3 3:13 3:13
HVAC_OVERVIEW_MODE_ZONE3 3:14 3:14
HVAC_OVERVIEW_FAN_ZONE3 3:15 3:15
HVAC_NAME_ZONE4 3:46
HVAC_OVERVIEW_TEMPERATURE_ZONE4 3:16 3:16
HVAC_OVERVIEW_COOL_POINT_ZONE4 3:17 3:17
HVAC_OVERVIEW_HEAT_POINT_ZONE4 3:18 3:18
HVAC_OVERVIEW_MODE_ZONE4 3:19 3:19
HVAC_OVERVIEW_FAN_ZONE4 3:20 3:20
HVAC_NAME_ZONE5 3:47
HVAC_OVERVIEW_TEMPERATURE_ZONE5 3:21 3:21
HVAC_OVERVIEW_COOL_POINT_ZONE5 3:22 3:22
HVAC_OVERVIEW_HEAT_POINT_ZONE5 3:23 3:23
HVAC_OVERVIEW_MODE_ZONE5 3:24 3:24
HVAC_OVERVIEW_FAN_ZONE5 3:25 3:25
HVAC_NAME_ZONE6 3:48
HVAC_OVERVIEW_TEMPERATURE_ZONE6 3:26 3:26
