Design XPress Installer’s Guide
Channel Map - Function Codes
Function Codes
Page Name Button Name Channel Port:Code Address Port:Code Level Port:Code
Logo
SETUP 0:73
Copy of InfoButton 1:88
Main Page
CONTROL_TP_1_BUTTON 1:1
CONTROL_TP_2_BUTTON 1:2
CONTROL_TP_3_BUTTON 1:3
CONTROL_TP_4_BUTTON 1:4
CONTROL_TP_5_BUTTON 1:5
CONTROL_TP_6_BUTTON 1:65
CONTROL_TP_7_BUTTON 1:7
AUD_TP_VOL_DN_BUTTON 1:11
AUD_TP_VOL_UP_BUTTON 1:12
AUD_TP_MUSIC_OFF_BUTTON 1:10
AUD_TP_VOL_LEVEL 1:13 1:1
CONTROL_TP_1_DATE 0:152
CONTROL_TP_1_TIME 0:142
Button 13 1:1
HELP-ABOUT
AMX_SETUP_BUTTON 0:73
SCREEN_NAME 1:88
SLEEP_BUTTON 1:8
SYSINFO_IWEATHER 1:197
Debug
CONTROL_DEBUG_1_BUTTON 1:9
CONTROL_DEBUG_2_BUTTON 1:19
CONTROL_DEBUG_3_BUTTON 1:66
System Information 1:88
WeatherConfig
info 1:216 1:216
SN 1:250
SN 1:251
Video Select
BUTTON_BACK 1:6
Setup 3:100 3:100
VIDEO_TP_INPUT1_BUTTON 1:101 1:101
VIDEO_TP_INPUT2_BUTTON 1:102 1:102
VIDEO_TP_INPUT3_BUTTON 1:103 1:103
VIDEO_TP_INPUT4_BUTTON 1:104 1:104
VIDEO_TP_INPUT5_BUTTON 1:105 1:105
VIDEO_TP_INPUT6_BUTTON 1:106 1:106
VIDEO_TP_INPUT7_BUTTON 1:107 1:107
VIDEO_TP_INPUT8_BUTTON 1:108 1:108
VIDEO_SELECT_BUTTON 3:100 3:100
VIDEO_FULL_SCREEN_BUTTON 3:100 3:100
